Analog Switches, Multiplexers, Demultiplexers

Mfr Part #	Quantity	Price	Series	Package	Product Status	Package / Case	Mounting Type	Operating Temperature	On-State Resistance (Max)	-3db Bandwidth	Supplier Device Package	Voltage - Supply, Single (V+)	Voltage - Supply, Dual (V±)	Charge Injection	Crosstalk	Switch Circuit	Multiplexer/Demultiplexer Circuit	Channel-to-Channel Matching (ΔRon)	Switch Time (Ton, Toff) (Max)	Channel Capacitance (CS(off), CD(off))	Current - Leakage (IS(off)) (Max)	Grade	Number of Circuits	Qualification
UM4684H IC SWITCH SPDT X 2 800MOHM 10CSP UNION SEMICONDUCTOR INTERNATIONAL LIMITED Datasheet	10,000 Marketplace	1 : $0.66 10 : $5.10 100 : $39.00 500 : $150.00 Tape & Reel (TR)		Tape & Reel (TR)	Active	10-WFBGA, CSPBGA	Surface Mount	-40°C ~ 85°C	800mOhm	20MHz	10-CSP (2.05x1.55)	1.8V ~ 5.5V	-	21pC	-69dB @ 100kHz	SPDT	2:1	500mOhm (Max)	82ns, 73ns	10pF	2nA	-	2	-
UM4717 IC SWITCH SPDT X 2 3OHM 10CSP UNION SEMICONDUCTOR INTERNATIONAL LIMITED Datasheet	21,000 Marketplace	2 : $1.10 10 : $4.20 100 : $33.00 500 : $125.00 Tape & Reel (TR)		Tape & Reel (TR)	Active	10-WFBGA, CSPBGA	Surface Mount	-40°C ~ 85°C	3Ohm	300MHz	10-CSP (1.86x1.36)	1.8V ~ 5.5V	-	-	-70dB @ 10MHz	SPDT	2:1	100mOhm	80ns, 40ns	-	500pA	-	2	-
UM4717Q IC SWITCH SPDT X 2 3.5OHM 10QFN UNION SEMICONDUCTOR INTERNATIONAL LIMITED Datasheet	9,966 Marketplace	1 : $0.55 10 : $4.20 100 : $33.00 500 : $125.00 Tape & Reel (TR)		Tape & Reel (TR)	Active	10-UFQFN	Surface Mount	-40°C ~ 85°C	3.5Ohm	300MHz	10-QFN (1.8x1.4)	1.8V ~ 5.5V	-	-	-70dB @ 10MHz	SPDT	2:1	500mOhm	80ns, 40ns	-	500pA	-	2	-
UM3670A High Speed, Low Voltage, Dual, D UNION SEMICONDUCTOR INTERNATIONAL LIMITED Datasheet	226,425 Marketplace	2 : $1.56 10 : $6.80 100 : $52.00 500 : $210.00 Tape & Reel (TR)	UM3670	Tape & Reel (TR)	Active	16-UFQFN	Surface Mount	-40°C ~ 85°C	10Ohm	300MHz	16-QFN (2.6x1.8)	1.8V ~ 5.5V	-	-	-60dB @ 10MHz	DPDT - NO/NC	2:2	-	20ns, 10ns	9pF, 9pF	-	-	2	-
UM3156 Low-Voltage SPDT Analog Switch UNION SEMICONDUCTOR INTERNATIONAL LIMITED Datasheet	308,224 Marketplace	2 : $0.40 10 : $1.50 100 : $12.00 500 : $45.00 Tape & Reel (TR)	UM3156	Tape & Reel (TR)	Active	6-TSSOP, SC-88, SOT-363	Surface Mount	-55°C ~ 125°C (TA)	15Ohm	230MHz	SOT-363	1.65V ~ 5.5V	-	9pC	-54dB @ 10MHz	SPDT - NO/NC	2:1	150mOhm	6.2ns, 3.8ns	7.5pF	100nA	-	1	-
UM7227MA High-Speed UART USB2.0 (480 Mbps UNION SEMICONDUCTOR INTERNATIONAL LIMITED Datasheet	12,353 Marketplace	2 : $1.46 10 : $5.80 100 : $43.00 500 : $190.00 Tape & Reel (TR)	UM7227	Tape & Reel (TR)	Active	10-TFSOP, 10-MSOP (0.118", 3.00mm Width)	Surface Mount	-40°C ~ 85°C	13Ohm	550MHz	10-MSOP	2.7V ~ 5.5V	-	-	-42dB @ 250MHz	DPDT - NO/NC	2:2	350mOhm	30ns, 25ns	4.5pF	1µA	-	2	-
UM3699A Dual DPDT Ultra-Low RON Analog S UNION SEMICONDUCTOR INTERNATIONAL LIMITED Datasheet	83,052 Marketplace	2 : $1.56 10 : $6.80 100 : $52.00 500 : $210.00 Tape & Reel (TR)	UM3699A	Tape & Reel (TR)	Active	16-WFQFN Exposed Pad	Surface Mount	-40°C ~ 85°C (TA)	550mOhm	20MHz	16-QFN (3x3)	1.65V ~ 5.5V	-	50pC	-62dB @ 100kHz	DPDT - NO/NC	2:2	50mOhm (Max)	50ns, 30ns	72pF	100nA	-	2	-
UM2268 IC SWITCH SPDT X 2 750MOHM 10QFN UNION SEMICONDUCTOR INTERNATIONAL LIMITED Datasheet	10,000 Marketplace	1 : $0.55 10 : $4.20 100 : $33.00 500 : $125.00 Tape & Reel (TR)		Tape & Reel (TR)	Active	10-UFQFN	Surface Mount	-40°C ~ 85°C	750mOhm	80MHz	10-QFN (1.8x1.4)	1.8V ~ 4.4V	-	4pC	-90dB @ 1MHz	SPDT	2:1	40mOhm	88ns, 16ns	-	1µA	-	2	-
UM7222MA IC SWITCH DPDT X 2 9OHM 10MSOP UNION SEMICONDUCTOR INTERNATIONAL LIMITED Datasheet	8,976 Marketplace	1 : $0.44 10 : $3.40 100 : $26.00 500 : $100.00 Tape & Reel (TR)		Tape & Reel (TR)	Active	10-TFSOP, 10-MSOP (0.118", 3.00mm Width)	Surface Mount	-40°C ~ 85°C	9Ohm	550MHz	10-MSOP	2.7V ~ 5.5V	-	-	-48dB @ 250MHz	DPDT	2:2	350mOhm	30ns, 25ns	2.5pF, 4.5pF	1µA	-	2	-
UM3670 High Speed, Low Voltage, Dual, D UNION SEMICONDUCTOR INTERNATIONAL LIMITED Datasheet	56,342 Marketplace	2 : $1.56 10 : $6.80 100 : $52.00 500 : $210.00 Tape & Reel (TR)	UM3670	Tape & Reel (TR)	Active	16-WFQFN Exposed Pad	Surface Mount	-40°C ~ 85°C	10Ohm	300MHz	16-QFN (3x3)	1.8V ~ 5.5V	-	-	-60dB @ 10MHz	DPDT - NO/NC	2:2	-	20ns, 10ns	9pF	-	-	2	-
