PMXB65ENE,147 _ Single FETs, MOSFETs_FETs, MOSFETs_Transistors_Discrete Semiconductor Products

Part Number	PMXB65ENE,147
Manufacturer	NXP Semiconductors
Other Part Numbers	2156-PMXB65ENE147-NX-ND 2156-PMXB65ENE147-NX NEXNXPPMXB65ENE,147
Description	NOW NEXPERIA PMXB65ENE - SMALL S
Detailed Description	N-Channel 30 V 3.2A (Ta) 400mW (Ta), 8.33W (Tc) Surface Mount DFN1010D-3
Datasheet	Datasheet

Category		Discrete Semiconductor Products Transistors FETs, MOSFETs Single FETs, MOSFETs
Manufacturer		NXP Semiconductors
Series
Packaging		Bulk
Part Status		Active
Package / Case		3-XDFN Exposed Pad
Mounting Type		Surface Mount
Operating Temperature		-55°C ~ 150°C (TJ)
Technology		MOSFET (Metal Oxide)
FET Type		N-Channel
Current - Continuous Drain (Id) @ 25°C		3.2A (Ta)
Rds On (Max) @ Id, Vgs		67mOhm @ 3.2A, 10V
Power Dissipation (Max)		400mW (Ta), 8.33W (Tc)
Vgs(th) (Max) @ Id		2.5V @ 250µA
Supplier Device Package		DFN1010D-3
Drive Voltage (Max Rds On, Min Rds On)		4.5V, 10V
Vgs (Max)		±20V
Drain to Source Voltage (Vdss)		30 V
Gate Charge (Qg) (Max) @ Vgs		11 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds		295 pF @ 15 V

RESOURCE TYPE		LINK
Datasheets		PMXB65ENE,147

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8541.29.0095
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		Vendor Undefined
RoHS Status		Not applicable
