Single FETs, MOSFETs_FETs, MOSFETs_Transistors_All Tested Limited_Integrated Circuits (ICs)_Semiconductors_Circuit Protection_Connectors_Cable Assemblies

Single FETs, MOSFETs

Packaging

Bag

Box

Bulk

Cut Tape (CT)

Strip

Tape & Box (TB)

Tape & Reel (TR)

Tray

Tube

Product Status

Active

Obsolete

Discontinued

Last Time Buy

Not For New Designs

Mounting Type

Chassis Mount

Surface Mount

Surface Mount, Wettable Flank

Through Hole

Technology

GaNFET (Cascode Gallium Nitride FET)

GaNFET (Gallium Nitride)

MOSFET (Metal Oxide)

SiC (Silicon Carbide Junction Transistor)

SiCFET (Cascode SiCJFET)

SiCFET (Silicon Carbide)

FET Type

N-Channel

P-Channel

FET Feature

Current Sensing

Depletion Mode

Logic Level Gate, 4V Drive

Schottky Diode (Body)

Schottky Diode (Isolated)

Temperature Sensing Diode

Grade

Automotive

Military

Mfr Part #	Quantity	Price	Series	Package	Product Status	Package / Case	Mounting Type	Operating Temperature	Technology	FET Type	Current - Continuous Drain (Id) @ 25°C	Rds On (Max) @ Id, Vgs	FET Feature	Power Dissipation (Max)	Vgs(th) (Max) @ Id	Supplier Device Package	Grade	Drive Voltage (Max Rds On, Min Rds On)	Vgs (Max)	Drain to Source Voltage (Vdss)	Gate Charge (Qg) (Max) @ Vgs	Input Capacitance (Ciss) (Max) @ Vds	Qualification
STFU10N80K5 MOSFET N-CH 800V 9A TO220FP STMicroelectronics Datasheet	946 In Stock	1 : $3.03 10 : $25.50 100 : $206.00 500 : $915.00 1,000 : $1,570.00 2,000 : $2,960.00 5,000 : $7,100.00 Tube	MDmesh™ K5	Tube	Active	TO-220-3 Full Pack	Through Hole	-55°C ~ 150°C (TJ)	MOSFET (Metal Oxide)	N-Channel	9A (Tc)	600mOhm @ 4.5A, 10V	-	30W (Tc)	5V @ 100µA	TO-220FP	-	10V	±30V	800 V	22 nC @ 10 V	635 pF @ 100 V	-
STF16N90K5 MOSFET N-CH 900V 15A TO220FP STMicroelectronics Datasheet	37 In Stock	1 : $6.64 50 : $263.00 100 : $451.00 500 : $2,005.00 1,000 : $3,430.00 2,000 : $6,460.00 Tube	MDmesh™ DK5	Tube	Active	TO-220-3 Full Pack	Through Hole	-55°C ~ 150°C (TJ)	MOSFET (Metal Oxide)	N-Channel	15A (Tc)	330mOhm @ 7.5A, 10V	-	30W (Tc)	5V @ 100µA	TO-220FP	-	10V	±30V	900 V	29.7 nC @ 10 V	1027 pF @ 100 V	-
2SK2534-TL-E NCH 10V DRIVE SERIES Sanyo Semiconductor/onsemi Datasheet	22,500 Marketplace	102 : $301.92 Bulk		Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
UPA2721GR-E1-AT N-CHANNEL POWER MOSFET Intersil (Renesas Electronics Corporation) Datasheet	342,500 Marketplace	176 : $300.96 Bulk		Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
SPW11N60S5 N-CHANNEL POWER MOSFET IR (Infineon Technologies) Datasheet	14,461 Marketplace	160 : $300.80 Bulk	CoolMOS™	Bulk	Active	TO-247-3	Through Hole	-55°C ~ 150°C (TJ)	MOSFET (Metal Oxide)	N-Channel	11A (Tc)	380mOhm @ 7A, 10V	-	125W (Tc)	5.5V @ 500µA	PG-TO247-3-21	-	10V	±20V	600 V	54 nC @ 10 V	1460 pF @ 25 V	-
IRFBG20PBF-BE3 MOSFET N-CH 1000V 1.4A TO220AB Vishay / Siliconix Datasheet	1,760 In Stock	1 : $1.76 50 : $71.00 100 : $117.00 500 : $495.00 1,000 : $840.00 2,000 : $1,580.00 5,000 : $3,800.00 10,000 : $7,400.00 Tube		Tube	Active	TO-220-3	Through Hole	-55°C ~ 150°C (TJ)	MOSFET (Metal Oxide)	N-Channel	1.4A (Tc)	11Ohm @ 840mA, 10V	-	54W (Tc)	4V @ 250µA	TO-220AB	-	10V	±20V	1000 V	38 nC @ 10 V	500 pF @ 25 V	-
G3R75MT12K SIC MOSFET N-CH 41A TO247-4 GeneSiC Semiconductor Datasheet	706 In Stock	1 : $10.77 10 : $97.10 25 : $232.75 100 : $875.00 250 : $2,097.50 500 : $4,070.00 1,000 : $7,890.00 Tube	G3R™	Tube	Active	TO-247-4	Through Hole	-55°C ~ 175°C (TJ)	SiCFET (Silicon Carbide)	N-Channel	41A (Tc)	90mOhm @ 20A, 15V	-	207W (Tc)	2.69V @ 7.5mA	TO-247-4	-	15V	+22V, -10V	1200 V	54 nC @ 15 V	1560 pF @ 800 V	-
G3R40MT12D SIC MOSFET N-CH 71A TO247-3 GeneSiC Semiconductor Datasheet	1,732 In Stock	1 : $17.42 10 : $159.00 25 : $383.25 100 : $1,452.00 250 : $3,500.00 500 : $6,810.00 Tube	G3R™	Tube	Active	TO-247-3	Through Hole	-55°C ~ 175°C (TJ)	SiCFET (Silicon Carbide)	N-Channel	71A (Tc)	48mOhm @ 35A, 15V	-	333W (Tc)	2.69V @ 10mA	TO-247-3	-	15V	±15V	1200 V	106 nC @ 15 V	2929 pF @ 800 V	-
IRFB9N60APBF-BE3 MOSFET N-CH 600V 9.2A TO220AB Vishay / Siliconix Datasheet	24 In Stock	1 : $2.96 50 : $119.00 100 : $196.00 500 : $825.00 1,000 : $1,400.00 2,000 : $2,660.00 5,000 : $6,400.00 Tube		Tube	Active	TO-220-3	Through Hole	-55°C ~ 150°C (TJ)	MOSFET (Metal Oxide)	N-Channel	9.2A (Tc)	750mOhm @ 5.5A, 10V	-	170W (Tc)	4V @ 250µA	TO-220AB	-	-	±30V	600 V	49 nC @ 10 V	1400 pF @ 25 V	-
IRFR214PBF-BE3 MOSFET N-CH 250V 2.2A DPAK Vishay / Siliconix Datasheet	2,849 In Stock	1 : $1.40 75 : $84.00 150 : $133.50 525 : $393.75 1,050 : $640.50 2,025 : $1,174.50 5,025 : $2,763.75 10,050 : $5,226.00 Tube		Tube	Active	TO-252-3, DPAK (2 Leads + Tab), SC-63	Surface Mount	-55°C ~ 150°C (TJ)	MOSFET (Metal Oxide)	N-Channel	2.2A (Tc)	2Ohm @ 1.3A, 10V	-	2.5W (Ta), 25W (Tc)	4V @ 250µA	TO-252AA	-	-	±20V	250 V	8.2 nC @ 10 V	140 pF @ 25 V	-

1
2
3
4
5
6
7
8
9
10
...
999
1000

PACKAGING	QUANTITY	UNIT PRICE	EXT PRICE
{{ p.name }}	{{ numberFormat(p.buyQty) }}	{{ priceFormat(p.unitPrice) }}	{{ priceFormat(p.totalPrice) }}
Total Amount: {{ priceFormat(quotes.total) }} (including {{ priceFormat(quotes.fee) }} fee)

Menu

Single FETs, MOSFETs

Manufacturer

Series

Packaging

Product Status

Package / Case

Mounting Type

Operating Temperature

Technology

FET Type

Current - Continuous Drain (Id) @ 25°C

Rds On (Max) @ Id, Vgs

FET Feature

Power Dissipation (Max)

Vgs(th) (Max) @ Id

Supplier Device Package

Grade

Drive Voltage (Max Rds On, Min Rds On)

Vgs (Max)

Drain to Source Voltage (Vdss)

Gate Charge (Qg) (Max) @ Vgs

Input Capacitance (Ciss) (Max) @ Vds

Qualification

Single FETs, MOSFETs

Manufacturer

Series

Packaging

Product Status

Package / Case

Mounting Type

Operating Temperature

Technology

FET Type

Current - Continuous Drain (Id) @ 25°C

Rds On (Max) @ Id, Vgs

FET Feature

Power Dissipation (Max)

Vgs(th) (Max) @ Id

Supplier Device Package

Grade

Drive Voltage (Max Rds On, Min Rds On)

Vgs (Max)

Drain to Source Voltage (Vdss)

Gate Charge (Qg) (Max) @ Vgs

Input Capacitance (Ciss) (Max) @ Vds

Qualification

Stocking Options

Environmental Options

Media

Marketplace Product
