Spade Connectors

Mfr Part #	Quantity	Price	Series	Package	Product Status	Features	Contact Finish	Color	Mounting Type	Wire Gauge	Insulation	Terminal Type	Stud/Tab Size	Length - Overall	Termination	Material - Insulation	Width - Outer Edges	Contact Material	Insulation Diameter	Length - Ring Center to Termination	Length - Termination	Tongue Inside Opening
PN22-6F-C CONN SPADE TERM 22-26AWG #6 YEL Panduit Corporation Datasheet	0 In Stock	Obsolete	Pan-Term®	Bulk	Obsolete	-	Tin	Yellow	Free Hanging (In-Line)	22-26 AWG	Insulated	Standard	6 Stud	0.770" (19.56mm)	Crimp	Polyamide (PA), Nylon	0.250" (6.35mm)	Copper	0.090" (2.29mm)	-	-	0.150" (3.81mm)
PV18-8FX-CY CONN SPADE TERM 18-22AWG #8 RED Panduit Corporation Datasheet	0 In Stock	Obsolete	Pan-Term®	Bulk	Obsolete	Brazed Seam	Tin	Red	Free Hanging (In-Line)	18-22 AWG	Insulated	Standard	8 Stud	0.890" (22.61mm)	Crimp	Vinyl	0.320" (8.13mm)	Copper	0.170" (4.32mm)	-	-	0.170" (4.32mm)
PMNF2-4F-C CONN SPADE TERM 14-16AWG M4 BLU Panduit Corporation Datasheet	0 In Stock	Obsolete	Pan-Term®	Bulk	Obsolete	Serrated Termination	Tin	Blue	Free Hanging (In-Line)	14-16 AWG	Insulated	Standard	M4 Stud	0.840" (21.34mm)	Crimp	-	0.310" (7.87mm)	Copper	-	-	-	-
PMNF2-6F-C CONN SPADE TERM 14-16AWG M6 BLU Panduit Corporation Datasheet	0 In Stock	Obsolete	Pan-Term®	Bulk	Obsolete	Serrated Termination	Tin	Blue	Free Hanging (In-Line)	14-16 AWG	Insulated	Standard	M6 Stud	1.031" (26.20mm)	Crimp	-	0.440" (11.18mm)	Copper	-	-	-	-
PNF14-10SLF-3K CONN SPADE TERM 14-16AWG #10 BLU Panduit Corporation Datasheet	0 In Stock	Obsolete	Pan-Term®	Tape & Reel (TR)	Obsolete	Serrated Termination	Tin	Blue	Free Hanging (In-Line)	14-16 AWG	Insulated	Spring, Snap	10 Stud	0.810" (20.57mm)	Crimp	Polyamide (PA), Nylon	0.330" (8.38mm)	Copper	0.162" (4.11mm)	-	-	0.190" (4.83mm)
PV14-6F-E CONN SPADE TERM 14-16AWG #6 BLU Panduit Corporation Datasheet	0 In Stock	Obsolete	Pan-Term®	Bulk	Obsolete	Brazed Seam, Serrated Termination	Tin	Blue	Free Hanging (In-Line)	14-16 AWG	Insulated	Standard	6 Stud	0.840" (21.34mm)	Crimp	Vinyl	0.280" (7.11mm)	Copper	0.170" (4.32mm)	-	-	0.150" (3.81mm)
PV10-6F-E CONN SPADE TERM 10-12AWG #6 YEL Panduit Corporation Datasheet	0 In Stock	Obsolete	Pan-Term®	Bulk	Obsolete	Brazed Seam	Tin	Yellow	Free Hanging (In-Line)	10-12 AWG	Insulated	Standard	6 Stud	1.010" (25.65mm)	Crimp	Vinyl	0.310" (7.87mm)	Copper	0.225" (5.72mm)	-	-	0.140" (3.56mm)
PV14-8F-E CONN SPADE TERM 14-16AWG #8 BLU Panduit Corporation Datasheet	0 In Stock	Obsolete	Pan-Term®	Bulk	Obsolete	Brazed Seam, Serrated Termination	Tin	Blue	Free Hanging (In-Line)	14-16 AWG	Insulated	Standard	8 Stud	0.900" (22.86mm)	Crimp	Vinyl	0.310" (7.87mm)	Copper	0.170" (4.32mm)	-	-	0.170" (4.32mm)
PMNF1-5F-C CONN SPADE TERM 18-22AWG M5 RED Panduit Corporation Datasheet	0 In Stock	Obsolete	Pan-Term®	Bulk	Obsolete	Serrated Termination	Tin	Red	Free Hanging (In-Line)	18-22 AWG	Insulated	Standard	M5 Stud	0.900" (22.86mm)	Crimp	Polyamide (PA), Nylon	0.350" (8.89mm)	Copper	0.148" (3.76mm)	-	-	0.250" (6.35mm)
PV18-6FX-CY CONN SPADE TERM 18-22AWG #6 RED Panduit Corporation Datasheet	0 In Stock	Obsolete	Pan-Term®	Bulk	Obsolete	Brazed Seam, Serrated Termination	Tin	Red	Free Hanging (In-Line)	18-22 AWG	Insulated	Standard	6 Stud	0.880" (22.35mm)	Crimp	Vinyl	0.300" (7.62mm)	Copper	0.170" (4.32mm)	-	-	0.150" (3.81mm)
