Spade Connectors

Mfr Part #	Quantity	Price	Series	Package	Product Status	Features	Contact Finish	Color	Mounting Type	Wire Gauge	Insulation	Terminal Type	Stud/Tab Size	Length - Overall	Termination	Material - Insulation	Width - Outer Edges	Contact Material	Insulation Diameter	Length - Ring Center to Termination	Length - Termination	Tongue Inside Opening
PN10-6F-L CONN SPADE TERM 10-12AWG #6 YEL Panduit Corporation Datasheet	2,582 In Stock	1 : $1.52 50 : $70.50 100 : $137.00 1,000 : $1,260.00 5,000 : $5,900.00 Bulk	Pan-Term®	Bulk	Active	Butted Seam	Tin	Yellow	Free Hanging (In-Line)	10-12 AWG	Insulated	Standard	6 Stud	1.000" (25.40mm)	Crimp	-	0.310" (7.87mm)	Copper	-	-	-	-
PN18-6F-C CONN SPADE TERM 18-22AWG #6 RED Panduit Corporation Datasheet	94 In Stock	1 : $1.31 10 : $12.80 100 : $118.00 1,000 : $1,080.00 5,000 : $5,100.00 Bulk	Pan-Term®	Bulk	Active	Butted Seam	Tin	Red	Free Hanging (In-Line)	18-22 AWG	Insulated	Standard	6 Stud	0.780" (19.81mm)	Crimp	Polyamide (PA), Nylon	0.300" (7.62mm)	Copper	0.145" (3.68mm)	-	-	0.150" (3.81mm)
PV10-8F-L CONN SPADE TERM 10-12AWG #8 YEL Panduit Corporation Datasheet	715 In Stock	1 : $1.08 50 : $50.00 100 : $97.00 1,000 : $890.00 5,000 : $4,200.00 Bulk	Pan-Term®	Bulk	Active	Brazed Seam	Tin	Yellow	Free Hanging (In-Line)	10-12 AWG	Insulated	Standard	8 Stud	1.040" (26.42mm)	Crimp	Vinyl	0.370" (9.40mm)	Copper	0.225" (5.72mm)	-	-	0.170" (4.32mm)
PN10-10LF-L CONN SPADE TERM 10-12AWG #10 YEL Panduit Corporation Datasheet	75 In Stock	1 : $1.65 50 : $76.00 100 : $148.00 1,000 : $1,360.00 5,000 : $6,400.00 Bulk	Pan-Term®	Bulk	Active	Butted Seam, Serrated Termination	Tin	Yellow	Free Hanging (In-Line)	10-12 AWG	Insulated	Spring, Snap	10 Stud	1.050" (26.67mm)	Crimp	-	0.340" (8.64mm)	Copper	-	-	-	-
PNF14-10LF-C CONN SPADE TERM 14-16AWG #10 BLU Panduit Corporation Datasheet	400 In Stock	1 : $1.69 10 : $16.40 25 : $40.00 50 : $78.00 100 : $152.00 500 : $740.00 1,000 : $1,390.00 Bulk	Pan-Term®	Bulk	Active	Serrated Termination	Tin	Blue	Free Hanging (In-Line)	14-16 AWG	Insulated	Spring, Snap	10 Stud	0.930" (23.62mm)	Crimp	-	0.330" (8.38mm)	Copper	-	-	-	-
PV10-14LF-L CONN SPADE TERM 10-12AWG #1/4 Panduit Corporation Datasheet	269 In Stock	1 : $1.69 50 : $78.00 100 : $152.00 1,000 : $1,390.00 5,000 : $6,550.00 Bulk	Pan-Term®	Bulk	Active	Serrated Termination	Tin	Yellow	Free Hanging (In-Line)	10-12 AWG	Insulated	Spring, Snap	1/4 Stud	1.190" (30.23mm)	Crimp	-	0.460" (11.68mm)	Copper	-	-	-	-
PV10-6LF-L CONN SPADE TERM 10-12AWG #6 YEL Panduit Corporation Datasheet	47 In Stock	1 : $1.37 10 : $13.30 25 : $32.50 50 : $63.00 100 : $123.00 500 : $600.00 1,000 : $1,130.00 Bulk	Pan-Term®	Bulk	Active	Serrated Termination	Tin	Yellow	Free Hanging (In-Line)	10-12 AWG	Insulated	Spring, Snap	6 Stud	1.030" (26.16mm)	Crimp	Vinyl	0.300" (7.62mm)	Copper	0.225" (5.72mm)	-	-	0.140" (3.56mm)
PMNF2-5F-C CONN SPADE TERM 14-16AWG M5 BLU Panduit Corporation Datasheet	79 In Stock	1 : $1.67 10 : $16.30 100 : $150.00 1,000 : $1,380.00 5,000 : $6,450.00 Bulk	Pan-Term®	Bulk	Active	Serrated Termination	Tin	Blue	Free Hanging (In-Line)	14-16 AWG	Insulated	Standard	M5 Stud	0.840" (21.34mm)	Crimp	Polyamide (PA66), Nylon 6/6	0.338" (8.58mm)	Copper	0.162" (4.11mm)	-	-	0.250" (6.35mm)
PV10-8LF-L CONN SPADE TERM 10-12AWG #8 YEL Panduit Corporation Datasheet	316 In Stock	1 : $1.22 50 : $56.50 100 : $110.00 1,000 : $1,000.00 5,000 : $4,700.00 Bulk	Pan-Term®	Bulk	Active	Serrated Termination	Tin	Yellow	Free Hanging (In-Line)	10-12 AWG	Insulated	Spring, Snap	8 Stud	1.050" (26.67mm)	Crimp	-	0.300" (7.62mm)	Copper	-	-	-	-
PN10-14F-L CONN SPADE TERM 10-12AWG #1/4 Panduit Corporation Datasheet	149 In Stock	1 : $1.64 10 : $16.00 25 : $38.75 50 : $75.50 100 : $147.00 500 : $715.00 1,000 : $1,350.00 Bulk	Pan-Term®	Bulk	Active	Butted Seam	Tin	Yellow	Free Hanging (In-Line)	10-12 AWG	Insulated	Standard	1/4 Stud	1.140" (28.96mm)	Crimp	-	0.490" (12.45mm)	Copper	-	-	-	-
