PTC Resettable Fuses

Mfr Part #	Quantity	Price	Series	Package	Product Status	Package / Case	Size / Dimension	Mounting Type	Type	Operating Temperature	Lead Spacing	Approval Agency	Current - Hold (Ih) (Max)	Current - Trip (It)	Voltage - Max	Ratings	Height - Seated (Max)	Thickness (Max)	Grade	Current - Max	Time to Trip	Resistance - Initial (Ri) (Min)	Resistance - Post Trip (R1) (Max)	Resistance - 25°C (Typ)	Qualification
PRG21BC0R2MM1RA PTC RESET FUSE 6V 750MA 0805 TOKO / Murata Datasheet	40,903 In Stock	4,000 : $1,600.00 8,000 : $2,800.00 12,000 : $4,080.00 20,000 : $6,800.00 28,000 : $9,240.00 Tape & Reel (TR)	POSISTOR®, PRG	Tape & Reel (TR) Cut Tape (CT)	Active	0805 (2012 Metric)	0.079" L x 0.049" W (2.00mm x 1.25mm)	Surface Mount	Ceramic	-20°C ~ 85°C	-	UL	750 mA	1.62 A	6V	-	-	0.043" (1.10mm)	-	10 A	-	-	-	200 mOhms	-
PRG18BC2R2MM1RB PTC RESET FUSE 12V 220MA 0603 TOKO / Murata Datasheet	1,919 In Stock	4,000 : $800.00 8,000 : $1,360.00 12,000 : $2,040.00 20,000 : $3,400.00 28,000 : $4,480.00 Tape & Reel (TR)	POSISTOR®, PRG	Tape & Reel (TR) Cut Tape (CT)	Active	0603 (1608 Metric)	0.063" L x 0.032" W (1.60mm x 0.80mm)	Surface Mount	Ceramic	-20°C ~ 85°C	-	UL	220 mA	500 mA	12V	-	-	0.037" (0.95mm)	-	6.5 A	-	-	-	2.2 Ohms	-
PRG21BC2R2MM1RA PTC RESET FUSE 16V 220MA 0805 TOKO / Murata Datasheet	8,012 In Stock	4,000 : $1,240.00 8,000 : $2,160.00 12,000 : $3,240.00 20,000 : $5,200.00 28,000 : $7,280.00 Tape & Reel (TR)	POSISTOR®, PRG	Tape & Reel (TR) Cut Tape (CT)	Active	0805 (2012 Metric)	0.079" L x 0.049" W (2.00mm x 1.25mm)	Surface Mount	Ceramic	-20°C ~ 85°C	-	UL	220 mA	500 mA	16V	-	-	0.043" (1.10mm)	-	9 A	-	-	-	2.2 Ohms	-
PRG18BC3R3MM1RB PTC RESET FUSE 16V 180MA 0603 TOKO / Murata Datasheet	33,632 In Stock	4,000 : $800.00 8,000 : $1,360.00 12,000 : $2,040.00 20,000 : $3,400.00 28,000 : $4,480.00 Tape & Reel (TR)	POSISTOR®, PRG	Tape & Reel (TR) Cut Tape (CT)	Active	0603 (1608 Metric)	0.063" L x 0.032" W (1.60mm x 0.80mm)	Surface Mount	Ceramic	-20°C ~ 85°C	-	UL	180 mA	400 mA	16V	-	-	0.037" (0.95mm)	-	6 A	-	-	-	3.3 Ohms	-
PRG18BB101MS1RB PTC RESET FUSE 16V 21MA 0603 TOKO / Murata Datasheet	2,646 In Stock	4,000 : $1,040.00 8,000 : $1,760.00 12,000 : $2,640.00 20,000 : $4,400.00 28,000 : $5,880.00 Tape & Reel (TR)	POSISTOR®, PRG	Tape & Reel (TR) Cut Tape (CT)	Active	0603 (1608 Metric)	0.063" L x 0.032" W (1.60mm x 0.80mm)	Surface Mount	Ceramic	-20°C ~ 85°C	-	-	21 mA	45 mA	16V	-	-	0.037" (0.95mm)	-	200 mA	-	-	-	100 Ohms	-
PRG21BC3R3MM1RA PTC RESET FUSE 20V 180MA 0805 TOKO / Murata Datasheet	9,909 In Stock	4,000 : $1,320.00 8,000 : $2,320.00 12,000 : $3,480.00 20,000 : $5,600.00 28,000 : $7,560.00 Tape & Reel (TR)	POSISTOR®, PRG	Tape & Reel (TR) Cut Tape (CT)	Active	0805 (2012 Metric)	0.079" L x 0.049" W (2.00mm x 1.25mm)	Surface Mount	Ceramic	-20°C ~ 85°C	-	UL	180 mA	400 mA	20V	-	-	0.043" (1.10mm)	-	7.5 A	-	-	-	3.3 Ohms	-
PRG21BB220MB1RK PTC RESET FUSE 20V 44MA 0805 TOKO / Murata Datasheet	5,603 In Stock	3,000 : $1,110.00 6,000 : $2,040.00 9,000 : $2,880.00 15,000 : $4,650.00 30,000 : $9,000.00 Tape & Reel (TR)	POSISTOR®, PRG	Tape & Reel (TR) Cut Tape (CT)	Active	0805 (2012 Metric)	0.079" L x 0.049" W (2.00mm x 1.25mm)	Surface Mount	Ceramic	-20°C ~ 60°C	-	UL	44 mA	91 mA	20V	-	-	0.057" (1.45mm)	-	1.1 A	-	-	-	22 Ohms	-
PRG18BC1R0MM1RB PTC RESET FUSE 6V 330MA 0603 TOKO / Murata Datasheet	1,745 In Stock	4,000 : $800.00 8,000 : $1,360.00 12,000 : $2,040.00 20,000 : $3,400.00 28,000 : $4,480.00 Tape & Reel (TR)	POSISTOR®, PRG	Tape & Reel (TR) Cut Tape (CT)	Active	0603 (1608 Metric)	0.063" L x 0.032" W (1.60mm x 0.80mm)	Surface Mount	Ceramic	-20°C ~ 85°C	-	UL	330 mA	740 mA	6V	-	-	0.037" (0.95mm)	-	7.5 A	-	-	-	1 Ohms	-
PRG18BC4R7MM1RB PTC RESET FUSE 20V 155MA 0603 TOKO / Murata Datasheet	4,260 In Stock	4,000 : $800.00 8,000 : $1,360.00 12,000 : $2,040.00 20,000 : $3,400.00 28,000 : $4,480.00 Tape & Reel (TR)	POSISTOR®, PRG	Tape & Reel (TR) Cut Tape (CT)	Active	0603 (1608 Metric)	0.063" L x 0.032" W (1.60mm x 0.80mm)	Surface Mount	Ceramic	-20°C ~ 85°C	-	UL	155 mA	330 mA	20V	-	-	0.037" (0.95mm)	-	5 A	-	-	-	4.7 Ohms	-
PRG18BC6R8MM1RB PTC RESET FUSE 20V 120MA 0603 TOKO / Murata Datasheet	7,674 In Stock	4,000 : $800.00 8,000 : $1,360.00 12,000 : $2,040.00 20,000 : $3,400.00 28,000 : $4,480.00 Tape & Reel (TR)	POSISTOR®, PRG	Tape & Reel (TR) Cut Tape (CT)	Active	0603 (1608 Metric)	0.063" L x 0.032" W (1.60mm x 0.80mm)	Surface Mount	Ceramic	-20°C ~ 85°C	-	UL	120 mA	260 mA	20V	-	-	0.037" (0.95mm)	-	3.5 A	-	-	-	6.8 Ohms	-
