Mfr Part #	Quantity	Price	Series	Package	Product Status	Display Type	Function	Memory Size	Interface	Type	Voltage - Supply	Sampling Rate (Per Second)	Voltage - Input (Max)	Channels	Input Impedance	Probe Type	Bandwidth	Rise Time (Typ)
T3DSOH1102-ISO 100MHZ 1GS/S 2CH 12MPTS/CH HANDH Teledyne LeCroy Datasheet	2 In Stock	1 : $3,995.02 Box		Box	Active	LCD - Color	Record, PlayBack, Save, DMM	12Mpts	USB	Handheld	100 ~ 240VAC	1G	CAT II 1000V, CAT III 600V	2	1M - 14pF	Passive (2)	100 MHz	3.5 ns
DHO924S 250MHz, 1.25GSa/s, 4 channels, 1 RIGOL Technologies Datasheet	121 Marketplace	1 : $899.00 Box	DHO900	Box	Active	LCD - Color	Record, Playback	50Mpts	RS232, USB	Bench	12VDC	1.25G	CAT I 300V	4 Analog	1M - 15pF	Passive (4)	250 MHz	1.4 ns
DHO814 100MHz, 1.25GSa/s, 4 channels RIGOL Technologies Datasheet	103 Marketplace	1 : $549.00 Box	DHO800	Box	Active	LCD - Color	Record, Playback	25Mpts	RS232, USB	Bench	12VDC	1.25G	CAT I 300V	4 Analog	1M - 15pF	Passive (4)	100 MHz	3.5 ns
MSO3354E-S MIXED SIGNALDIGITAL OSCILLOSCOP Uni-Trend Technology Datasheet	7 Marketplace	1 : $2,999.00 Retail Package	MSO/UPO3000E	Retail Package	Active	-	-	-	-	Bench	100 ~ 240VAC	-	-	4	1M - 18pF	-	350 MHz	1 ns
MSO2204-S MIXED SIGNAL DGTL OSCILLOSCOPE Uni-Trend Technology Datasheet	7 Marketplace	1 : $1,499.00 Retail Package	MSO/UPO2000	Retail Package	Active	-	-	-	-	Bench	100 ~ 240VAC	-	400V	4	1M - 16pF	-	200 MHz	1.8 ns
MSO2104 MIXED SIGNAL DGTL OSCILLOSCOPE Uni-Trend Technology Datasheet	12 Marketplace	1 : $1,199.00 Retail Package	MSO/UPO2000	Retail Package	Active	-	-	-	-	Bench	100 ~ 240VAC	-	400V	4	1M - 16pF	-	100 MHz	3.5 ns
MSO3352E MIXED SIGNAL DGTL OSCILLOSCOPE Uni-Trend Technology Datasheet	6 Marketplace	1 : $2,019.00 Retail Package	MSO/UPO3000E	Retail Package	Active	-	-	-	-	Bench	100 ~ 240VAC	-	-	2	1M - 18pF	-	350 MHz	1 ns
MSO2204 MIXED SIGNAL DGTL OSCILLOSCOPE Uni-Trend Technology Datasheet	7 Marketplace	1 : $1,399.00 Retail Package	MSO/UPO2000	Retail Package	Active	-	-	-	-	Bench	100 ~ 240VAC	-	400V	4	1M - 16pF	-	200 MHz	1.8 ns
DHO1202 High Resolution 2 Channel, 200 M RIGOL Technologies Datasheet	41 Marketplace	1 : $1,149.00 Box	DHO1000	Box	Active	LCD - Color	Record, Playback	100Mpts	RS232, USB	Bench	100 ~ 240VAC	2G	CAT I 300V	2 Analog	1M - 19pF	Passive (2)	200 MHz	1.75 ns
XDS4502 XDS4502 10.4" 4CH 500MHz Oscope OWON Technology Lilliput Electronics Datasheet	97 Marketplace	1 : $3,599.00 Tape & Box (TB)	XDS4000	Tape & Box (TB)	Active	LCD - Color	Record	-	Ethernet, RS232, USB	Bench	-	250M	400V	2	10M	-	500 MHz	0.7 ns
