Part Number	XF2J102412AR100BYOMZ
Manufacturer	Omron Electronic Components
Other Part Numbers	XF2J102412AR100BYOMZ-ND XF2J-1024-12A-R100 BY OMZ
Description	CONN FPC VERT 10POS 0.5MM SMD
Detailed Description	10 Position FPC Connector Contacts, Vertical - 1 Sided 0.020" (0.50mm) Surface Mount

Category		Connectors, Interconnects FFC, FPC (Flat Flexible) Connectors FFC, FPC (Flat Flexible) Connector Assemblies
Manufacturer		Omron Electronic Components
Series		XF2J
Packaging		Bulk
Part Status		Obsolete
Features		Zero Insertion Force (ZIF)
Contact Finish		Gold
Voltage Rating		50V
Current Rating (Amps)		0.5A
Mounting Type		Surface Mount
Number of Positions		10
Pitch		0.020" (0.50mm)
Operating Temperature		-30°C ~ 85°C
Termination		Solder
Height Above Board		0.163" (4.15mm)
Contact Finish Thickness		5.90µin (0.150µm)
Locking Feature		Slide Lock
Material Flammability Rating		UL94 V-0
Contact Material		Copper Alloy
FFC, FCB Thickness		0.30mm
Housing Material		Polyamide (PA46), Nylon 4/6
Cable End Type		Tapered
Housing Color		Natural
Actuator Color		Black
Mating Cycles		30
Flat Flex Type		FPC
Connector/Contact Type		Contacts, Vertical - 1 Sided

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4051
Moisture Sensitivity Level (MSL)		1 (Unlimited)

This product is no longer manufactured.
