WPB2512QLR004FYR-A

WPB2512QLR004FYR-A

Part Number	WPB2512QLR004FYR-A
Manufacturer	Wickmann / Littelfuse
Other Part Numbers	18-WPB2512QLR004FYR-ATR-ND 18-WPB2512QLR004FYR-ACT-ND 18-WPB2512QLR004FYR-ADKR-ND 18-WPB2512QLR004FYR-ADKR 18-WPB2512QLR004FYR-ACT 18-WPB2512QLR004FYR-ATR
Description	AEQ-Q200 RESISTOR
Detailed Description	4 mOhms ±1% 2W Chip Resistor 2512 (6432 Metric) Current Sense, High Voltage Metal Element
Manufacturer Standard Lead Time	14 weeks
Datasheet	Datasheet

Product Attributes

Category		Resistors Chip Resistor - Surface Mount
Manufacturer		Wickmann / Littelfuse
Series		WPB
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Power (Watts)		2W
Tolerance		±1%
Features		Current Sense, High Voltage
Package / Case		2512 (6432 Metric)
Temperature Coefficient		±50ppm/°C
Size / Dimension		0.252" L x 0.126" W (6.40mm x 3.20mm)
Composition		Metal Element
Operating Temperature		-55°C ~ 170°C
Number of Terminations		2
Supplier Device Package		2512
Height - Seated (Max)		0.043" (1.10mm)
Resistance		4 mOhms

Documents & Media

RESOURCE TYPE		LINK
Datasheets		WPB2512QLR004FYR-A

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8533.21.0030
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant

In Stock: 4000

Can ship immediately.
