WCL3225-121-R _ Fixed Inductors_Inductors, Coils, Chokes

Part Number	WCL3225-121-R
Manufacturer	PowerStor (Eaton)
Other Part Numbers	283-WCL3225-121-RTR-ND -875-WCL3225-121-RCT 283-WCL3225-121-RTR
Description	FIXED IND 120UH 85MA 7.9 OHM SMD
Detailed Description	120 µH Unshielded Drum Core, Wirewound Inductor 85 mA 7.9Ohm Max 1210 (3225 Metric)
Manufacturer Standard Lead Time	13 weeks
Datasheet	Datasheet

Category		Inductors, Coils, Chokes Fixed Inductors
Manufacturer		PowerStor (Eaton)
Series		WCL3225
Packaging		Tape & Reel (TR)
Part Status		Active
Tolerance		±5%
Package / Case		1210 (3225 Metric)
Size / Dimension		0.138" L x 0.114" W (3.50mm x 2.90mm)
Mounting Type		Surface Mount
Shielding		Unshielded
Type		Drum Core, Wirewound
Operating Temperature		-40°C ~ 85°C
DC Resistance (DCR)		7.9Ohm Max
Q @ Freq		8 @ 796kHz
Frequency - Self Resonant		4MHz
Material - Core		Ceramic
Inductance Frequency - Test		796 kHz
Supplier Device Package		1210
Height - Seated (Max)		0.089" (2.25mm)
Inductance		120 µH
Current Rating (Amps)		85 mA

RESOURCE TYPE		LINK
Datasheets		WCL3225-121-R

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.50.8000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		RoHS Compliant
