UP0.4C-150-R

UP0.4C-150-R

Part Number	UP0.4C-150-R
Manufacturer	PowerStor (Eaton)
Other Part Numbers	283-UP0.4C-150-RTR-ND UP0.4C-150-R-ND -875-UP0.4C-150-RCT 283-UP0.4C-150-RTR UP0.4C-150-ND UP0.4C-150 -875-UP0.4C-150-RTR-ND -875-UP0.4C-150-RTR UP0-4C-150-R
Description	FIXED IND 15UH 950MA 250MOHM SMD
Detailed Description	15 µH Unshielded Drum Core, Wirewound Inductor 950 mA 250mOhm Max Nonstandard
Manufacturer Standard Lead Time	13 weeks
Datasheet	Datasheet

Product Attributes

Category		Inductors, Coils, Chokes Fixed Inductors
Manufacturer		PowerStor (Eaton)
Series		UNI-PAC™ 0.4C
Packaging		Tape & Reel (TR)
Part Status		Active
Tolerance		±20%
Package / Case		Nonstandard
Size / Dimension		0.260" L x 0.175" W (6.60mm x 4.45mm)
Mounting Type		Surface Mount
Shielding		Unshielded
Type		Drum Core, Wirewound
Operating Temperature		-40°C ~ 85°C
DC Resistance (DCR)		250mOhm Max
Current - Saturation (Isat)		940mA
Material - Core		Ferrite
Inductance Frequency - Test		100 kHz
Height - Seated (Max)		0.115" (2.92mm)
Inductance		15 µH
Current Rating (Amps)		950 mA

Documents & Media

RESOURCE TYPE		LINK
Datasheets		UP0.4C-150-R
Datasheets		Multiple Devices 31/Aug/2013
Datasheets		Shipping Box and Labels 05/Jan/2018

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.50.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		RoHS Compliant
