TSD05DYFR

TSD05DYFR

Part Number	TSD05DYFR
Manufacturer	Texas Instruments
Other Part Numbers	296-TSD05DYFRTR-ND 296-TSD05DYFRCT-ND 296-TSD05DYFRDKR-ND 296-TSD05DYFRCT 296-TSD05DYFRDKR 296-TSD05DYFRTR
Description	IC
Detailed Description	9V (Typ) Clamp 60A (8/20µs) Ipp Tvs Diode Surface Mount SOD-323
Manufacturer Standard Lead Time	12 weeks
Datasheet	Datasheet

Product Attributes

Category		Circuit Protection Transient Voltage Suppressors (TVS) TVS Diodes
Manufacturer		Texas Instruments
Series
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Package / Case		SC-76, SOD-323
Mounting Type		Surface Mount
Type		Zener
Operating Temperature		-55°C ~ 150°C (TA)
Applications		USB
Capacitance @ Frequency		19pF @ 1MHz
Current - Peak Pulse (10/1000µs)		60A (8/20µs)
Voltage - Reverse Standoff (Typ)		5.5V (Max)
Supplier Device Package		SOD-323
Unidirectional Channels		1
Voltage - Breakdown (Min)		6V
Voltage - Clamping (Max) @ Ipp		9V (Typ)
Power - Peak Pulse		530W
Power Line Protection		No

Documents & Media

RESOURCE TYPE		LINK
Datasheets		TSD05DYFR
Datasheets		TSD05
PCN Design/Specification		SOT devices Marking 05//Feb/2024

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8541.10.0080
Moisture Sensitivity Level (MSL)		3 (168 Hours)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
