TLP3073(LF1,F _ Triac, SCR Output Optoisolators_Optoisolators_Isolators

Part Number	TLP3073(LF1,F
Manufacturer	Toshiba Electronic Devices and Storage Corporation
Other Part Numbers	264-TLP3073(LF1,F-ND TLP3073(LF1F 264-TLP3073(LF1,F TLP3073(LF1F-ND
Description	OPTO TRIAC COUPLER; NON-ZERO-VOL
Detailed Description	Optoisolator Triac Output 5000Vrms 1 Channel 6-SO, 5 Lead
Manufacturer Standard Lead Time	24 weeks
Datasheet	Datasheet

Category		Isolators Optoisolators Triac, SCR Output Optoisolators
Manufacturer		Toshiba Electronic Devices and Storage Corporation
Series
Packaging		Tube
Part Status		Active
Package / Case		6-SMD (5 Leads), Gull Wing
Output Type		Triac
Mounting Type		Surface Mount
Operating Temperature		-40°C ~ 100°C
Voltage - Forward (Vf) (Typ)		1.15V
Voltage - Isolation		5000Vrms
Approval Agency		CQC, cUR, UR
Current - Hold (Ih)		1mA (Typ)
Supplier Device Package		6-SO, 5 Lead
Zero Crossing Circuit		No
Static dV/dt (Min)		2kV/µs (Typ)
Current - LED Trigger (Ift) (Max)		5mA
Number of Channels		1
Current - On State (It (RMS)) (Max)		100 mA
Voltage - Off State		800 V
Current - DC Forward (If) (Max)		50 mA

RESOURCE TYPE		LINK
Datasheets		TLP3073(LF1,F

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8541.49.8000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant

Can ship immediately.

QUANTITY

PACKAGING	QUANTITY	UNIT PRICE	EXT PRICE
{{ p.name }}	{{ numberFormat(p.buyQty) }}	{{ priceFormat(p.unitPrice) }}	{{ priceFormat(p.totalPrice) }}
Total Amount: {{ priceFormat(quotes.total) }} (including {{ priceFormat(quotes.fee) }} fee)

QUANTITY	UNIT PRICE	EXT PRICE
{{ numberFormat(price.break_quantity) }}	{{ priceFormat(price.unit_price) }}	{{ priceFormat(price.break_quantity * price.unit_price) }}

Detailed pricing is currently unavailable.

Detailed packaging information is temporarily unavailable.
