TLP267J(E _ Triac, SCR Output Optoisolators_Optoisolators_Isolators

Part Number	TLP267J(E
Manufacturer	Toshiba Electronic Devices and Storage Corporation
Other Part Numbers	TLP267J(E-ND
Description	X36 PB-F TRIAC COUPLER LOW TRIGG
Detailed Description	Optoisolator Triac Output 3750Vrms 1 Channel 6-SOP
Manufacturer Standard Lead Time	36 weeks
Datasheet	Datasheet

Category		Isolators Optoisolators Triac, SCR Output Optoisolators
Manufacturer		Toshiba Electronic Devices and Storage Corporation
Series
Packaging		Tube
Part Status		Active
Package / Case		6-SOIC (0.173", 4.40mm Width), 4 Leads
Output Type		Triac
Mounting Type		Surface Mount
Operating Temperature		-40°C ~ 100°C
Voltage - Forward (Vf) (Typ)		1.27V
Voltage - Isolation		3750Vrms
Approval Agency		CQC, cUR, UR
Current - Hold (Ih)		200µA (Typ)
Turn On Time		100µs
Supplier Device Package		6-SOP
Zero Crossing Circuit		No
Static dV/dt (Min)		500V/µs (Typ)
Current - LED Trigger (Ift) (Max)		3mA
Number of Channels		1
Current - On State (It (RMS)) (Max)		70 mA
Voltage - Off State		600 V
Current - DC Forward (If) (Max)		30 mA

RESOURCE TYPE		LINK
Datasheets		TLP267J(E

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8541.49.8000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
