TBP05P1-762-08BE _ Headers, Plugs and Sockets_Terminal Blocks_Connectors, Interconnects

Part Number	TBP05P1-762-08BE
Manufacturer	CUI Devices
Other Part Numbers	2223-TBP05P1-762-08BE-ND 2223-TBP05P1-762-08BE
Description	2~24 POLES, PLUGGABLE, VERTICAL,
Detailed Description	8 Position Terminal Block Plug, Female Sockets 0.300" (7.62mm) 180° Free Hanging (In-Line)
Manufacturer Standard Lead Time	13 weeks
Datasheet	Datasheet

Category		Connectors, Interconnects Terminal Blocks Headers, Plugs and Sockets
Manufacturer		CUI Devices
Series		TBP05P1-762
Packaging		Box
Part Status		Active
Features		Retention Latches (Non-Wire Side)
Color		Blue
Mounting Type		Free Hanging (In-Line)
Number of Positions		8
Pitch		0.300" (7.62mm)
Screw Size		M3
Type		Plug, Female Sockets
Operating Temperature		-40°C ~ 105°C
Termination Style		Screw
Material Flammability Rating		UL94 V-0
Current - IEC		10A
Number of Levels		1
Wire Gauge or Range - AWG		12-28 AWG
Wire Gauge or Range - mm²		0.5-2.5mm²
Positions Per Level		8
Contact Material		Copper Alloy
Plug Wire Entry		180°
Housing Material		Polyamide (PA66), Nylon 6/6
Torque - Screw		0.5 Nm (4.4 Lb-In)
Contact Mating Finish		Nickel
Wire Strip Length		7-8mm
Insulation Height		0.713" (18.10mm)
Current - UL		15 A
Voltage - IEC		1 kV
Voltage - UL		300 V

RESOURCE TYPE		LINK
Datasheets		TBP05P1-762-08BE

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.90.4000
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
