SNJ54LS684J

SNJ54LS684J

Part Number	SNJ54LS684J
Manufacturer	Texas Instruments
Other Part Numbers	296-SNJ54LS684J-ND 296-SNJ54LS684J
Description	IC COMPARATOR MAG 8BIT 20CDIP
Detailed Description	Magnitude Comparator Bit Active Low Output A=B, A>B 20-CDIP
Datasheet	Datasheet

Product Attributes

Category		Integrated Circuits (ICs) Logic Comparators
Manufacturer		Texas Instruments
Series		54LS
Packaging		Tube
Part Status		Active
Package / Case		20-CDIP (0.300", 7.62mm)
Mounting Type		Through Hole
Output		Active Low
Type		Magnitude Comparator
Operating Temperature		-55°C ~ 125°C
Voltage - Supply		4.5V ~ 5.5V
Current - Quiescent (Iq)		65 mA
Current - Output High, Low		400µA, 12mA
Supplier Device Package		20-CDIP
Max Propagation Delay @ V, Max CL		30ns @ 5V, 45pF
Output Function		A=B, A>B
Number of Bits		8

Documents & Media

RESOURCE TYPE		LINK
Datasheets		SNJ54LS684J

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8542.39.0001
Moisture Sensitivity Level (MSL)		Not Applicable
RoHS Status		ROHS3 Compliant
