SNJ54AHCT14FK

SNJ54AHCT14FK

Part Number	SNJ54AHCT14FK
Manufacturer	Texas Instruments
Other Part Numbers	296-SNJ54AHCT14FK-ND 296-SNJ54AHCT14FK
Description	IC INVERT SCHMITT 6CH 6IN 20LCCC
Detailed Description	Inverter IC 6 Channel Schmitt Trigger 20-LCCC (8.89x8.89)
Datasheet	Datasheet

Product Attributes

Category		Integrated Circuits (ICs) Logic Gates and Inverters
Manufacturer		Texas Instruments
Series		54AHCT
Packaging		Tube
Part Status		Active
Features		Schmitt Trigger
Package / Case		20-CLCC
Mounting Type		Surface Mount
Logic Type		Inverter
Operating Temperature		-55°C ~ 125°C
Voltage - Supply		4.5V ~ 5.5V
Current - Output High, Low		8mA, 8mA
Number of Inputs		6
Supplier Device Package		20-LCCC (8.89x8.89)
Input Logic Level - High		1.9V ~ 2.1V
Input Logic Level - Low		1.5V ~ 1.7V
Max Propagation Delay @ V, Max CL		8ns @ 5V, 50pF
Number of Circuits		6
Current - Quiescent (Max)		2 µA

Documents & Media

RESOURCE TYPE		LINK
Datasheets		SNJ54AHCT14FK
Datasheets		SNx4AHCT14

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
