SN74BCT640NS

Part Number
SN74BCT640NS
Manufacturer Texas Instruments
Other Part Numbers
2156-SN74BCT640NS-ND
TEXTISSN74BCT640NS
2156-SN74BCT640NS
Description IC TXRX INVERT 5.5V 20SO
Detailed Description Transceiver, Inverting 1 Element 8 Bit per Element 3-State Output 20-SO
Datasheet Datasheet

Product Attributes

Category
Manufacturer Texas Instruments
Series
74BCT
Packaging
Bulk
Part Status Active
Package / Case 20-SOIC (0.209", 5.30mm Width)
Output Type 3-State
Mounting Type Surface Mount
Number of Elements 1
Logic Type Transceiver, Inverting
Operating Temperature 0°C ~ 70°C (TA)
Voltage - Supply 4.5V ~ 5.5V
Number of Bits per Element 8
Current - Output High, Low 3mA, 24mA; 15mA, 64mA
Supplier Device Package 20-SO

Documents & Media

RESOURCE TYPE LINK
Datasheets SN74BCT640NS

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8542.39.0001
Moisture Sensitivity Level (MSL) 3 (168 Hours)
REACH Status Vendor Undefined
RoHS Status Not applicable
