SD53-150-R

SD53-150-R

Part Number	SD53-150-R
Manufacturer	PowerStor (Eaton)
Other Part Numbers	513-1458-2-ND 513-1458-1-ND 513-1458-6-ND 513-1458-6 513-1458-2 513-1458-1 SD53150R
Description	FIXED IND 15UH 1.1A 142 MOHM SMD
Detailed Description	15 µH Shielded Drum Core, Wirewound Inductor 1.1 A 142mOhm Max Nonstandard
Manufacturer Standard Lead Time	13 weeks
Datasheet	Datasheet

Product Attributes

Category		Inductors, Coils, Chokes Fixed Inductors
Manufacturer		PowerStor (Eaton)
Series		SD53
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Tolerance		±20%
Package / Case		Nonstandard
Size / Dimension		0.205" L x 0.205" W (5.20mm x 5.20mm)
Mounting Type		Surface Mount
Shielding		Shielded
Type		Drum Core, Wirewound
Operating Temperature		-40°C ~ 125°C
DC Resistance (DCR)		142mOhm Max
Current - Saturation (Isat)		1.1A
Material - Core		Ferrite
Inductance Frequency - Test		100 kHz
Height - Seated (Max)		0.118" (3.00mm)
Inductance		15 µH
Current Rating (Amps)		1.1 A

Documents & Media

RESOURCE TYPE		LINK
Datasheets		SD53-150-R
Datasheets		Shipping Box and Labels 05/Jan/2018

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.50.8000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant

In Stock: 40376

Can ship immediately.
