RG1782-3

RG1782-3

Part Number	RG1782-3
Manufacturer	Electrocube
Other Part Numbers	3845-RG1782-3-ND 3845-RG1782-3
Description	RC NETWORK, 0.1 MFD, 47 OHM, 250
Detailed Description	RC EMI Filter 1st Order Low Pass 1 Channel R = 47Ohm, C = 0.1µF Radial

Product Attributes

Category		Filters EMI/RFI Filters (LC, RC Networks)
Manufacturer		Electrocube
Series
Packaging		Box
Part Status		Active
Voltage - Rated		600V
Package / Case		Radial
Size / Dimension		1.000" L x 0.380" W (25.40mm x 9.65mm)
Mounting Type		Through Hole
Type		Low Pass
Operating Temperature		-40°C ~ 80°C
Values		R = 47Ohm, C = 0.1µF
Height		0.660" (16.76mm)
Filter Order		1st
Applications		General Purpose
Technology		RC
ESD Protection		No
Number of Channels		1

Documents & Media

RESOURCE TYPE		LINK

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
