RBQ-12/33-D48PBSH-C _ DC DC Converters_Power Supplies

Part Number	RBQ-12/33-D48PBSH-C
Manufacturer	Murata Power Solutions
Other Part Numbers	RBQ-12/33-D48PBSH-C-ND
Description	DC DC CONVERTER 11.85V 391W
Detailed Description	Intermediate Bus Converter DC DC Converter 1 Output 11.85V 33A 36V - 75V Input

Category		Power Supplies - Board Mount DC DC Converters
Manufacturer		Murata Power Solutions
Series		RBQ-12/33-D48 (400W)
Packaging		Tray
Part Status		Obsolete
Features		Remote On/Off, OCP, OTP, SCP, UVLO
Package / Case		5-DIP Module, 1/4 Brick
Size / Dimension		2.30" L x 1.45" W x 0.50" H (58.4mm x 36.8mm x 12.6mm)
Mounting Type		Through Hole
Type		Intermediate Bus Converter
Operating Temperature		-40°C ~ 85°C
Applications		ITE (Commercial)
Voltage - Input (Max)		75V
Efficiency		96%
Current - Output (Max)		33A
Voltage - Input (Min)		36V
Voltage - Output 1		11.85V
Control Features		Enable, Active High
Power (Watts)		391 W
Number of Outputs		1
Voltage - Isolation		2.25 kV

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.40.9580
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected

This product is no longer manufactured.
