R577452102

Part Number
R577452102
Manufacturer Radiall USA, Inc.
Other Part Numbers
2201-R577452102-ND
R577.452.102
2201-R577452102
Description IC RF SWITCH DPDT 18GHZ
Detailed Description RF Switch IC General Purpose DPDT 50Ohm
Manufacturer Standard Lead Time 4 weeks
Datasheet Datasheet

Product Attributes

Category
Manufacturer Radiall USA, Inc.
Series
RAMSES
Packaging
Bulk
Part Status Active
Package / Case Module, SMA Connectors
Impedance 50Ohm
Circuit DPDT
RF Type General Purpose
Operating Temperature -40°C ~ 85°C
Voltage - Supply 10.2V ~ 13V
Insertion Loss 0.5dB (max)
Frequency Range 0Hz ~ 18GHz
Test Frequency 18GHz
Isolation 60dB (min)

Documents & Media

RESOURCE TYPE LINK
Datasheets R577452102

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
Moisture Sensitivity Level (MSL) Not Applicable
RoHS Status ROHS3 Compliant
