PXE30-24D12 _ DC DC Converters_Power Supplies

Part Number	PXE30-24D12
Manufacturer	TDK-Lambda, Inc.
Other Part Numbers	285-PXE30-24D12-ND 285-1542-ND PXE30-24D12 PXE3024D12 285-1542 285-PXE30-24D12
Description	DC DC CONVERTER +/-12V 30W
Detailed Description	Isolated Module DC DC Converter 2 Output 12V -12V 1.25A, 1.25A 18V - 36V Input
Manufacturer Standard Lead Time	12 weeks
Datasheet	Datasheet

Category		Power Supplies - Board Mount DC DC Converters
Manufacturer		TDK-Lambda, Inc.
Series		PXE (30W)
Packaging		Bulk
Part Status		Active
Features		Remote On/Off, OCP, OVP, SCP
Package / Case		8-DIP Module, 7 Leads
Size / Dimension		2.00" L x 1.60" W x 0.40" H (50.8mm x 40.6mm x 8.6mm)
Mounting Type		Through Hole
Type		Isolated Module
Operating Temperature		-40°C ~ 100°C
Applications		ITE (Commercial)
Voltage - Input (Max)		36V
Efficiency		88%
Current - Output (Max)		1.25A, 1.25A
Voltage - Input (Min)		18V
Voltage - Output 1		12V
Voltage - Output 2		-12V
Power (Watts)		30 W
Number of Outputs		2
Voltage - Isolation		1.6 kV

ATTRIBUTE		DESCRIPTION
California Prop 65		California Prop 65 Information
ECCN		EAR99
HTSUS		8504.40.9580
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
