PSA30W-190A-R-C2 12MM _ AC DC Desktop, Wall Power Adapters_Power Supplies

Part Number	PSA30W-190A-R-C2 12MM
Manufacturer	PHIHONG USA
Other Part Numbers	993-1285-ND PSA30W-190A-C2 12MM 993-1285
Description	AC/DC DESKTOP ADAPTER 18V 29W
Detailed Description	18V 29 W AC/DC External Desktop (Class II) Adapter Cord (Sold Separately) Input

Category		Power Supplies - External/Internal (Off-Board) AC DC Desktop, Wall Power Adapters
Manufacturer		PHIHONG USA
Series		PSA30W (30W)
Packaging		Box
Part Status		Obsolete
Size / Dimension		3.14" L x 1.38" W x 0.94" H (80.0mm x 35.0mm x 24.0mm)
Voltage - Output		18V
Polarization		Positive Center
Output Connector		Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 12.0mm
Voltage - Input		90 ~ 264 VAC
Cord Length		59" (1.50m)
Operating Temperature		0°C ~ 40°C
Applications		ITE (Commercial)
Input Type		Cord (Sold Separately)
Approval Agency		CE, cULus, TUVgs
Form		Desktop (Class II)
Efficiency		Level V
Current - Output (Max)		1.6A
Input Connector		IEC 320-C8
Region Utilized		International
No Load Power Consumption		200mW (Max)
Power (Watts)		29 W

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.40.7001
Moisture Sensitivity Level (MSL)		Not Applicable

This product is no longer manufactured.
