PGT6541NLT

Part Number
PGT6541NLT
Manufacturer Pulse Larsen Antenna
Other Part Numbers
553-PGT6541NLTTR-ND
553-PGT6541NLTCT-ND
553-PGT6541NLTDKR-ND
553-PGT6541NLTCT
553-PGT6541NLTTR
553-PGT6541NLTDKR
Description PWR XFMR SMD
Manufacturer Standard Lead Time 15 weeks
Datasheet Datasheet

Product Attributes

Category
Manufacturer Pulse Larsen Antenna
Series
Packaging
Tape & Reel (TR)
Cut Tape (CT)
Part Status Active
Size / Dimension 28.60mm L x 20.00mm W
Mounting Type Surface Mount
Termination Style Surface Mount
Primary Winding(s) Dual
Secondary Winding(s) Dual
Voltage - Isolation 4400Vrms
Current - Output (Max) 300mA
Voltage - Primary 5V
Height - Seated (Max) 12.50mm
Voltage - Secondary (Full Load) 7V
Center Tap No

Documents & Media

RESOURCE TYPE LINK
Datasheets PGT6541NLT

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.32.0000
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
RoHS Status ROHS3 Compliant

In Stock: 265

Can ship immediately.
