Part Number |
PDA080B-1A6G
|
---|---|
Manufacturer | PHIHONG USA |
Other Part Numbers |
993-1273-ND
PDA080B-1A6G-R
993-1273
|
Description | LED DRIVER CC AC/DC 34-48V 1.67A |
Detailed Description | 1.67A 34 ~ 48V Constant Current LED Driver AC DC Converter Topology 1 Output |
Category | ||
---|---|---|
Manufacturer | PHIHONG USA | |
Series |
PDA (80W)
|
|
Packaging |
Box
|
|
Part Status | Obsolete | |
Features | OCP, OVP, SCP | |
Size / Dimension | 9.50" L x 1.70" W x 1.20" H (241.0mm x 43.0mm x 30.5mm) | |
Voltage - Output | 34 ~ 48V | |
Type | Constant Current | |
Operating Temperature | -40°C ~ 60°C | |
Termination Style | Wire Leads | |
Voltage - Input (Max) | 304VAC | |
Approval Agency | CE, cULus | |
Ratings | IP67 | |
Efficiency | 85% | |
Topology | AC DC Converter | |
Current - Output (Max) | 1.67A | |
Voltage - Input (Min) | 90VAC | |
Power (Watts) | 80 W | |
Number of Outputs | 1 | |
Voltage - Isolation | 4.242 kV | |
DigiKey Programmable | Not Verified |
RESOURCE TYPE | LINK |
---|
ATTRIBUTE | DESCRIPTION | |
---|---|---|
ECCN | EAR99 | |
HTSUS | 8504.40.9580 | |
Moisture Sensitivity Level (MSL) | Not Applicable |
