PCSDR73-560M-RC

Part Number
PCSDR73-560M-RC
Manufacturer Allied Components International
Other Part Numbers
3475-PCSDR73-560M-RCTR-ND
3475-PCSDR73-560M-RCTR
Description 56UH 20% PWR CHIP SHIELDED IND.
Detailed Description 56 µH Shielded Inductor 975 mA 359.4mOhm Nonstandard
Datasheet Datasheet

Product Attributes

Category
Manufacturer Allied Components International
Series
Packaging
Tape & Reel (TR)
Part Status Active
Tolerance ±20%
Package / Case Nonstandard
Size / Dimension 0.287" L x 0.287" W (7.30mm x 7.30mm)
Mounting Type Surface Mount
Shielding Shielded
Operating Temperature -55°C ~ 125°C
DC Resistance (DCR) 359.4mOhm
Current - Saturation (Isat) 1.075A
Inductance Frequency - Test 100 kHz
Height - Seated (Max) 0.138" (3.50mm)
Inductance 56 µH
Current Rating (Amps) 975 mA

Documents & Media

RESOURCE TYPE LINK
Datasheets PCSDR73-560M-RC

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.50.4000
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH info available upon request
RoHS Status RoHS Compliant
