PCHC420R8-1R5M-RC

PCHC420R8-1R5M-RC

Part Number	PCHC420R8-1R5M-RC
Manufacturer	Allied Components International
Other Part Numbers	3475-PCHC420R8-1R5M-RCTR-ND 3475-PCHC420R8-1R5M-RCTR
Description	1.5uH +/-20% SMD Molded PwrChoke
Detailed Description	1.5 µH Shielded Inductor 4 A 46mOhm Max Nonstandard
Datasheet	Datasheet

Product Attributes

Category		Inductors, Coils, Chokes Fixed Inductors
Manufacturer		Allied Components International
Series		PCHC420R8
Packaging		Tape & Reel (TR)
Part Status		Active
Tolerance		±20%
Package / Case		Nonstandard
Size / Dimension		0.181" L x 0.161" W (4.60mm x 4.10mm)
Mounting Type		Surface Mount
Shielding		Shielded
Operating Temperature		-55°C ~ 125°C
DC Resistance (DCR)		46mOhm Max
Current - Saturation (Isat)		6A
Inductance Frequency - Test		100 kHz
Height - Seated (Max)		0.079" (2.00mm)
Inductance		1.5 µH
Current Rating (Amps)		4 A

Documents & Media

RESOURCE TYPE		LINK
Datasheets		PCHC420R8-1R5M-RC

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.50.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
