PCHC1265HP-2R7M

Part Number
PCHC1265HP-2R7M
Manufacturer Allied Components International
Other Part Numbers
3475-PCHC1265HP-2R7MTR-ND
3475-PCHC1265HP-2R7MTR
3475-PCHC1265HP-2R7M-RCTR-ND
PCHC1265HP-2R7M-RC
3475-PCHC1265HP-2R7M-RCTR
Description 2.7H 20% POWER CHOKE HIGH CURREN
Detailed Description 2.7 µH Shielded Inductor 20 A 5.5mOhm Max Nonstandard
Datasheet Datasheet

Product Attributes

Category
Manufacturer Allied Components International
Series
Packaging
Tape & Reel (TR)
Part Status Active
Tolerance ±20%
Package / Case Nonstandard
Size / Dimension 0.531" L x 0.492" W (13.50mm x 12.50mm)
Mounting Type Surface Mount
Shielding Shielded
Operating Temperature -40°C ~ 125°C
DC Resistance (DCR) 5.5mOhm Max
Current - Saturation (Isat) 32A
Inductance Frequency - Test 100 kHz
Height - Seated (Max) 0.256" (6.50mm)
Inductance 2.7 µH
Current Rating (Amps) 20 A

Documents & Media

RESOURCE TYPE LINK
Datasheets PCHC1265HP-2R7M

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.50.4000
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH info available upon request
RoHS Status ROHS3 Compliant

Available To Order

PACKAGING QUANTITY UNIT PRICE EXT PRICE
{{ p.name }} {{ numberFormat(p.buyQty) }} {{ priceFormat(p.unitPrice) }} {{ priceFormat(p.totalPrice) }}
Total Amount: {{ priceFormat(quotes.total) }} (including {{ priceFormat(quotes.fee) }} fee)

{{ package.name }}

QUANTITY UNIT PRICE EXT PRICE
{{ numberFormat(price.break_quantity) }} {{ priceFormat(price.unit_price) }} {{ priceFormat(price.break_quantity * price.unit_price) }}
Detailed pricing is currently unavailable.
Detailed packaging information is temporarily unavailable.
