PC1004-3R8M-RC

PC1004-3R8M-RC

Part Number	PC1004-3R8M-RC
Manufacturer	Allied Components International
Other Part Numbers	3475-PC1004-3R8M-RCTR-ND 3475-PC1004-3R8M-RCTR
Description	3.8H 20% POWER CHIP INDUCTOR
Detailed Description	3.8 µH Unshielded Wirewound Inductor 4.2 A 20mOhm Max Nonstandard
Datasheet	Datasheet

Product Attributes

Category		Inductors, Coils, Chokes Fixed Inductors
Manufacturer		Allied Components International
Series		PC1004
Packaging		Tape & Reel (TR)
Part Status		Active
Tolerance		±20%
Package / Case		Nonstandard
Size / Dimension		0.394" L x 0.354" W (10.00mm x 9.00mm)
Mounting Type		Surface Mount
Shielding		Unshielded
Type		Wirewound
Operating Temperature		-40°C ~ 85°C
DC Resistance (DCR)		20mOhm Max
Inductance Frequency - Test		7.96 MHz
Height - Seated (Max)		0.177" (4.50mm)
Inductance		3.8 µH
Current Rating (Amps)		4.2 A

Documents & Media

RESOURCE TYPE		LINK
Datasheets		PC1004-3R8M-RC

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.50.4000
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH info available upon request
RoHS Status		ROHS3 Compliant
