PAH-53/8.5-D48PB-C _ DC DC Converters_Power Supplies

Part Number	PAH-53/8.5-D48PB-C
Manufacturer	Murata Power Solutions
Other Part Numbers	811-2794-ND 811-2794 PAH5385D48PBC PAH-53
Description	DC DC CONVERTER 53V 450W
Detailed Description	Isolated Module DC DC Converter 1 Output 53V 8.5A 36V - 75V Input

Category		Power Supplies - Board Mount DC DC Converters
Manufacturer		Murata Power Solutions
Series		PAH (450W)
Packaging		Tray
Part Status		Obsolete
Features		Remote On/Off, OCP, OTP, OVP, SCP, UVLO
Package / Case		9-DIP Module, 1/2 Brick
Size / Dimension		2.40" L x 2.30" W x 0.50" H (61.0mm x 58.4mm x 12.7mm)
Mounting Type		Through Hole
Type		Isolated Module
Operating Temperature		-40°C ~ 85°C
Applications		ITE (Commercial)
Voltage - Input (Max)		75V
Efficiency		94%
Current - Output (Max)		8.5A
Voltage - Input (Min)		36V
Voltage - Output 1		53V
Control Features		Enable, Active High
Power (Watts)		450 W
Number of Outputs		1
Voltage - Isolation		2.25 kV

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.40.9580
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant

This product is no longer manufactured.
