NC7S86P5

NC7S86P5

Part Number	NC7S86P5
Manufacturer	Fairchild Semiconductor
Other Part Numbers	2156-NC7S86P5-ND 2156-NC7S86P5 FAIFSCNC7S86P5
Description	IC GATE XOR 1CH 2-INP SC70-5
Detailed Description	XOR (Exclusive OR) IC 1 Channel SC-70-5

Product Attributes

Category		Integrated Circuits (ICs) Logic Gates and Inverters
Manufacturer		Fairchild Semiconductor
Series		7S
Packaging		Bulk
Part Status		Active
Package / Case		5-TSSOP, SC-70-5, SOT-353
Mounting Type		Surface Mount
Logic Type		XOR (Exclusive OR)
Operating Temperature		-40°C ~ 85°C
Voltage - Supply		2V ~ 6V
Current - Output High, Low		2.6mA, 2.6mA
Number of Inputs		2
Supplier Device Package		SC-70-5
Input Logic Level - High		1.5V
Input Logic Level - Low		0.5V
Max Propagation Delay @ V, Max CL		17ns @ 6V, 50pF
Number of Circuits		1
Current - Quiescent (Max)		1 µA
