MSS1038-104MLC

Part Number
MSS1038-104MLC
Manufacturer COILCRAFT
Other Part Numbers
2457-MSS1038-104MLC-ND
2457-MSS1038-104MLC
Description FIXED IND 100UH 1.45A 304MOHM SM
Detailed Description 100 µH Shielded Drum Core Inductor 1.45 A 304mOhm Max Nonstandard
Datasheet Datasheet

Product Attributes

Category
Manufacturer COILCRAFT
Series
MSS1038
Packaging
Tape & Reel (TR)
Part Status Active
Tolerance ±20%
Package / Case Nonstandard
Size / Dimension 0.402" L x 0.394" W (10.20mm x 10.00mm)
Mounting Type Surface Mount
Shielding Shielded
Type Drum Core
Operating Temperature -40°C ~ 85°C
DC Resistance (DCR) 304mOhm Max
Frequency - Self Resonant 6MHz
Ratings AEC-Q200
Current - Saturation (Isat) 1.02A
Material - Core Ferrite
Inductance Frequency - Test 100 kHz
Height - Seated (Max) 0.157" (4.00mm)
Inductance 100 µH
Current Rating (Amps) 1.45 A

Documents & Media

RESOURCE TYPE LINK
Datasheets MSS1038-104MLC

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.50.8000
RoHS Status ROHS3 Compliant
