MP4601EF-LF-Z

MP4601EF-LF-Z

Part Number	MP4601EF-LF-Z
Manufacturer	MPS (Monolithic Power Systems)
Other Part Numbers	MP4601EF-LF-Z-ND
Description	IC LED DRV RGLTR PWM 16TSSOP
Detailed Description	LED Driver IC 1 Output DC DC Regulator Step-Down (Buck), Step-Up (Boost) Analog, PWM Dimming 2.5A (Switch) 16-TSSOP-EP
Datasheet	Datasheet

Product Attributes

Category		Integrated Circuits (ICs) Power Management (PMIC) LED Drivers
Manufacturer		MPS (Monolithic Power Systems)
Series
Packaging		Tape & Reel (TR)
Part Status		Not For New Designs
Package / Case		16-TSSOP (0.173", 4.40mm Width) Exposed Pad
Mounting Type		Surface Mount
Number of Outputs		1
Frequency		280kHz
Type		DC DC Regulator
Operating Temperature		-20°C ~ 85°C (TA)
Applications		Backlight
Current - Output / Channel		2.5A (Switch)
Internal Switch(s)		Yes
Topology		Step-Down (Buck), Step-Up (Boost)
Supplier Device Package		16-TSSOP-EP
Dimming		Analog, PWM
Voltage - Supply (Min)		4.5V
Voltage - Supply (Max)		75V
