Part Number	MC9S08SH32CTLR
Manufacturer	NXP Semiconductors
Other Part Numbers	MC9S08SH32CTLR-ND 2156-MC9S08SH32CTLR NXPNXPMC9S08SH32CTLR 935309917518
Description	IC MCU 8BIT 32KB FLASH 28TSSOP
Detailed Description	S08 S08 Microcontroller IC 8-Bit 40MHz 32KB (32K x 8) FLASH 28-TSSOP
Manufacturer Standard Lead Time	13 weeks
Datasheet	Datasheet

Category		Integrated Circuits (ICs) Embedded Microcontrollers
Manufacturer		NXP Semiconductors
Series		S08
Packaging		Tape & Reel (TR)
Part Status		Active
Package / Case		28-TSSOP (0.173", 4.40mm Width)
Mounting Type		Surface Mount
Speed		40MHz
Program Memory Size		32KB (32K x 8)
RAM Size		1K x 8
Operating Temperature		-40°C ~ 85°C (TA)
Oscillator Type		Internal
Program Memory Type		FLASH
Core Processor		S08
Data Converters		A/D 16x10b
Core Size		8-Bit
Voltage - Supply (Vcc/Vdd)		2.7V ~ 5.5V
Connectivity		I2C, LINbus, SCI, SPI
Peripherals		LVD, POR, PWM, WDT
Supplier Device Package		28-TSSOP
Number of I/O		23
DigiKey Programmable		Not Verified

RESOURCE TYPE		LINK
Datasheets		MC9S08SH32CTLR
Datasheets		NXP USA Inc REACH
Datasheets		NXP USA Inc RoHS Cert
Datasheets		Mult Dev Site Chgs 18/Dec/2020
Datasheets		Automated Packing Implementation 05/Jul/2023
Datasheets		Mult Dev Pkg Seal 15/Dec/2020
