MC908AP16ACFA _ Microcontrollers_Embedded_Integrated Circuits (ICs)

Part Number	MC908AP16ACFA
Manufacturer	Motorola
Other Part Numbers	2156-MC908AP16ACFA-ND 2156-MC908AP16ACFA FREMOTMC908AP16ACFA
Description	8-BIT, FLASH, 68HC08 CPU, 8MHZ
Detailed Description	M68HC08 HC08 Microcontroller IC 8-Bit 8MHz 16KB (16K x 8) FLASH 48-LQFP (7x7)

Category		Integrated Circuits (ICs) Embedded Microcontrollers
Manufacturer		Motorola
Series		HC08
Packaging		Bulk
Part Status		Active
Package / Case		48-LQFP
Mounting Type		Surface Mount
Speed		8MHz
Program Memory Size		16KB (16K x 8)
RAM Size		1K x 8
Operating Temperature		-40°C ~ 85°C (TA)
Oscillator Type		External, Internal
Program Memory Type		FLASH
Core Processor		M68HC08
Data Converters		A/D 8x10b SAR
Core Size		8-Bit
Voltage - Supply (Vcc/Vdd)		4.5V ~ 5.5V
Connectivity		I2C, SCI, SPI
Peripherals		LED, LVD, POR, PWM
Supplier Device Package		48-LQFP (7x7)
Number of I/O		31
DigiKey Programmable		Not Verified

RESOURCE TYPE		LINK

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8542.31.0001
Moisture Sensitivity Level (MSL)		3 (168 Hours)
REACH Status		Vendor Undefined
RoHS Status		RoHS non-compliant
