Part Number	MAX535BCUA
Manufacturer	Maxim Integrated / Analog Devices
Other Part Numbers	MAX535BCUA-ND
Description	IC DAC 13BIT V-OUT 8UMAX
Detailed Description	13 Bit Digital to Analog Converter 1 8-uMAX/uSOP
Datasheet	Datasheet

Category		Integrated Circuits (ICs) Data Acquisition Digital to Analog Converters (DAC)
Manufacturer		Maxim Integrated / Analog Devices
Series
Packaging		Tube
Part Status		Obsolete
Package / Case		8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Output Type		Voltage - Buffered
Mounting Type		Surface Mount
Number of Bits		13
Data Interface		SPI
Reference Type		External
Operating Temperature		0°C ~ 70°C
Voltage - Supply, Analog		5V
Voltage - Supply, Digital		5V
Settling Time		16µs (Typ)
Supplier Device Package		8-uMAX/uSOP
Architecture		R-2R
Number of D/A Converters		1
INL/DNL (LSB)		±1 (Max), ±1 (Max)
Differential Output		No
DigiKey Programmable		Not Verified

RESOURCE TYPE		LINK
Datasheets		MAX535BCUA
Datasheets		How Signal Chains and PLCs Impact Our Lives
Datasheets		Force/Sense DAC Applications
Datasheets		3V/5V DACs Support Intelligent Current Loop
Datasheets		Damage from a Lightning Bolt or a Spark
Datasheets		Maxim Integrated RoHS Cert
Datasheets		Maxim Integrated REACH
Datasheets		Multiple Devices 22/Mar/2015
Datasheets		Part Numbering System

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8542.39.0001
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		RoHS non-compliant

This product is no longer manufactured.
