MAX4420CPA

Part Number
MAX4420CPA
Manufacturer Maxim Integrated / Analog Devices
Other Part Numbers
MAX4420CPA-ND
Description IC GATE DRVR LOW-SIDE 8DIP
Detailed Description Low-Side Gate Driver IC Non-Inverting 8-PDIP
Datasheet Datasheet

Product Attributes

Category
Manufacturer Maxim Integrated / Analog Devices
Series
Packaging
Tube
Part Status Obsolete
Package / Case 8-DIP (0.300", 7.62mm)
Mounting Type Through Hole
Operating Temperature 0°C ~ 70°C (TA)
Voltage - Supply 4.5V ~ 18V
Input Type Non-Inverting
Supplier Device Package 8-PDIP
Rise / Fall Time (Typ) 25ns, 25ns
Channel Type Single
Driven Configuration Low-Side
Number of Drivers 1
Gate Type N-Channel, P-Channel MOSFET
Logic Voltage - VIL, VIH 0.8V, 2.4V
Current - Peak Output (Source, Sink) 6A, 6A
DigiKey Programmable Not Verified

Documents & Media

RESOURCE TYPE LINK
Datasheets MAX4420CPA
Datasheets Maxim Integrated RoHS Cert
Datasheets Maxim Integrated REACH
Datasheets Part Numbering System

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8542.39.0001
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
RoHS Status RoHS non-compliant

Obsolete

This product is no longer manufactured.
