LY T68B-T2-45-0-30-R18-XX _ LED Indication

Part Number	LY T68B-T2-45-0-30-R18-XX
Manufacturer	ams-OSRAM USA INC.
Other Part Numbers	475-LYT68B-T2-45-0-30-R18-XX-ND 475-LYT68B-T2-45-0-30-R18-XX-ND Q65111A3097 4991-LYT68B-T2-45-0-30-R18-XX 475-LYT68B-T2-45-0-30-R18-XX 4991-LYT68B-T2-45-0-30-R18-XX-ND
Description	LED YELLOW CLEAR 2PLCC SMD
Detailed Description	Yellow 589nm LED Indication - Discrete 2.1V 2-PLCC

Category		Optoelectronics LED Indication - Discrete
Manufacturer		ams-OSRAM USA INC.
Series		TOPLED® Black Surface
Packaging		Bulk
Part Status		Obsolete
Package / Case		2-PLCC
Color		Yellow
Size / Dimension		3.20mm L x 1.30mm W
Mounting Type		Surface Mount
Millicandela Rating		402.5mcd
Voltage - Forward (Vf) (Typ)		2.1V
Lens Color		Colorless
Current - Test		30mA
Viewing Angle		120°
Height (Max)		2.10mm
Wavelength - Peak		594nm
Wavelength - Dominant		589nm
Supplier Device Package		2-PLCC
Lens Transparency		Clear
Lens Style		Round with Flat Top
Lens Size		2.40mm Dia

RESOURCE TYPE		LINK

This product is no longer manufactured.
