LSWSS-105-D-02-GT-LF _ Headers, Receptacles, Female Sockets_Rectangular Connectors_Connectors, Interconnects

Part Number	LSWSS-105-D-02-GT-LF
Manufacturer	Major League Electronics
Other Part Numbers	2611-LSWSS-105-D-02-GT-LF-ND 2611-LSWSS-105-D-02-GT-LF
Description	.100 Socket
Detailed Description	10 Position Receptacle Connector 0.100" (2.54mm) Through Hole Gold
Datasheet	Datasheet

Category		Connectors, Interconnects Rectangular Connectors Headers, Receptacles, Female Sockets
Manufacturer		Major League Electronics
Series		LSWSS-1-D
Packaging		Bag
Part Status		Active
Connector Type		Receptacle
Current Rating (Amps)		3A
Mounting Type		Through Hole
Number of Positions		10
Style		Board to Board
Operating Temperature		-40°C ~ 105°C
Contact Type		Forked
Fastening Type		Push-Pull
Number of Positions Loaded		All
Termination		Solder
Contact Material		Phosphor Bronze
Insulation Color		Black
Pitch - Mating		0.100" (2.54mm)
Contact Finish - Mating		Gold
Contact Finish Thickness - Mating		Flash
Contact Finish - Post		Tin
Contact Shape		Square
Contact Length - Post		0.118" (3.00mm)
Insulation Height		0.578" (14.68mm)
Insulation Material		Polyamide (PA6T), Nylon 6T
Row Spacing - Mating		0.100" (2.54mm)
Number of Rows		2

RESOURCE TYPE		LINK
Datasheets		LSWSS-105-D-02-GT-LF

ATTRIBUTE		DESCRIPTION
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		RoHS Compliant
