LM2574HVM-12/NOPB _ Voltage Regulators - DC DC Switching Regulators_Power Management (PMIC)_Integrated Circuits (ICs)

Part Number	LM2574HVM-12/NOPB
Manufacturer	National Semiconductor
Other Part Numbers	2156-LM2574HVM-12/NOPB-ND NATNSCLM2574HVM-12/NOPB 2156-LM2574HVM-12/NOPB
Description	IC REG BUCK 12V 500MA 14SOIC
Detailed Description	Buck Switching Regulator IC Positive Fixed 12V 1 Output 500mA 14-SOIC (0.295", 7.50mm Width)

Category		Integrated Circuits (ICs) Power Management (PMIC) Voltage Regulators - DC DC Switching Regulators
Manufacturer		National Semiconductor
Series		SIMPLE SWITCHER®
Packaging		Bulk
Part Status		Active
Package / Case		14-SOIC (0.295", 7.50mm Width)
Output Type		Fixed
Mounting Type		Surface Mount
Number of Outputs		1
Function		Step-Down
Current - Output		500mA
Operating Temperature		-40°C ~ 125°C (TJ)
Output Configuration		Positive
Frequency - Switching		52kHz
Voltage - Input (Max)		60V
Topology		Buck
Supplier Device Package		14-SOIC
Synchronous Rectifier		No
Voltage - Input (Min)		4V
Voltage - Output (Min/Fixed)		12V
