Part Number |
KSW30B-1000
|
---|---|
Manufacturer | OK Industries (Jonard Tools) |
Other Part Numbers |
K531-ND
K531
KSW30B-1000-ND
Q1145328A
KSW30B1000
|
Description | WIRE WW 30AWG PVDF BLUE 1000' |
Detailed Description | Wire Wrap 30 AWG Blue Polyvinylidene Fluoride (PVDF) 1000' (304.80m) |
Datasheet | Datasheet |
Category | ||
---|---|---|
Manufacturer | OK Industries (Jonard Tools) | |
Series |
KSW
|
|
Packaging |
Roll
|
|
Part Status | Obsolete | |
Length | 1000' (304.80m) | |
Wire Gauge | 30 AWG | |
Jacket (Insulation) Material | Polyvinylidene Fluoride (PVDF) | |
Jacket (Insulation) Diameter | 0.019" (0.50mm) | |
Ratings | UL Style 1423 | |
Jacket (Insulation) Thickness | 0.004" (0.09mm) | |
Conductor Material | Copper, Bare | |
Conductor Diameter | 0.010" (0.25mm) | |
Jacket Color | Blue | |
Conductor Plating | Silver |
RESOURCE TYPE | LINK | |
---|---|---|
Datasheets | KSW30B-1000 | |
Datasheets | Jonard CA Prop 65 | |
Datasheets | Jonard Tools REACH | |
Datasheets | Jonard Tools RoHS Cert | |
Datasheets | DK OBS NOTICE |
ATTRIBUTE | DESCRIPTION | |
---|---|---|
California Prop 65 | California Prop 65 Information | |
ECCN | EAR99 | |
HTSUS | 8544.49.3080 | |
Moisture Sensitivity Level (MSL) | Not Applicable | |
REACH Status | REACH Unaffected | |
RoHS Status | ROHS3 Compliant |
