IRS2109PBF

Part Number
IRS2109PBF
Manufacturer International Rectifier
Other Part Numbers
2156-IRS2109PBF-ND
2156-IRS2109PBF
INFIRFIRS2109PBF
Description IRS2109 - GATE DRIVER
Detailed Description Half-Bridge Gate Driver IC Non-Inverting 8-PDIP

Product Attributes

Category
Manufacturer International Rectifier
Series
Packaging
Bulk
Part Status Active
Package / Case 8-DIP (0.300", 7.62mm)
Mounting Type Through Hole
Operating Temperature -40°C ~ 150°C (TJ)
Voltage - Supply 10V ~ 20V
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 600 V
Supplier Device Package 8-PDIP
Rise / Fall Time (Typ) 100ns, 35ns
Channel Type Synchronous
Driven Configuration Half-Bridge
Number of Drivers 2
Gate Type IGBT, N-Channel MOSFET
Logic Voltage - VIL, VIH 0.8V, 2.5V
Current - Peak Output (Source, Sink) 290mA, 600mA
DigiKey Programmable Not Verified

Documents & Media

RESOURCE TYPE LINK

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8542.39.0001
