Category | ||
---|---|---|
Manufacturer | Broadcom | |
Series |
HRPG
|
|
Packaging |
Bulk
|
|
Part Status | Active | |
Output Type | Quadrature (Incremental) | |
Mounting Type | Panel Mount | |
Orientation | Vertical | |
Termination Style | Cable with Connector | |
Voltage - Supply | 5V | |
Encoder Type | Optical | |
Detent | Yes | |
Pulses per Revolution | 32 | |
Actuator Type | 6mm Dia Round End | |
Built in Switch | No | |
Rotational Life (Cycles Min) | 1M |
RESOURCE TYPE | LINK | |
---|---|---|
Datasheets | HRPG-AD32#54C | |
Datasheets | HRPGyyyy#yyC DESIGN 07/May/2024 |
ATTRIBUTE | DESCRIPTION | |
---|---|---|
ECCN | EAR99 | |
HTSUS | 8543.70.4500 | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
REACH Status | REACH Unaffected | |
RoHS Status | ROHS3 Compliant |
