HM79-50270LFTR13

Part Number
HM79-50270LFTR13
Manufacturer TT Electronics/BI Magnetics
Other Part Numbers
987-1243-1-ND
HM79-50270LFTR
987-1243-1
HM7950270LFTR13
987-1243-2
987-1243-6
Description FIXED IND 27UH 1.44A 100 MOHM
Detailed Description 27 µH Unshielded Wirewound Inductor 1.44 A 100mOhm Max Nonstandard

Product Attributes

Category
Manufacturer TT Electronics/BI Magnetics
Series
HM79
Packaging
Cut Tape (CT)
Part Status Discontinued
Tolerance ±20%
Package / Case Nonstandard
Size / Dimension 0.394" L x 0.354" W (10.00mm x 9.00mm)
Mounting Type Surface Mount
Shielding Unshielded
Type Wirewound
Operating Temperature -40°C ~ 125°C
DC Resistance (DCR) 100mOhm Max
Inductance Frequency - Test 1 kHz
Height - Seated (Max) 0.157" (4.00mm)
Inductance 27 µH
Current Rating (Amps) 1.44 A

Documents & Media

RESOURCE TYPE LINK

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.50.4000
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected

Discontinued

This product is no longer for sale.
