Part Number |
HI5760/6IB
|
---|---|
Manufacturer | Harris Corporation |
Other Part Numbers |
2156-HI5760/6IB-HC-ND
HARHARHI5760/6IB
2156-HI5760/6IB-HC
|
Description | IC DAC 10BIT A-OUT 28SOIC |
Detailed Description | 10 Bit Digital to Analog Converter 1 28-SOIC |
Category | ||
---|---|---|
Manufacturer | Harris Corporation | |
Series | ||
Packaging |
Tube
|
|
Part Status | Obsolete | |
Package / Case | 28-SOIC (0.295", 7.50mm Width) | |
Output Type | Current - Unbuffered | |
Mounting Type | Surface Mount | |
Number of Bits | 10 | |
Data Interface | Parallel | |
Reference Type | External, Internal | |
Operating Temperature | -40°C ~ 85°C | |
Voltage - Supply, Analog | 2.7V ~ 5.5V | |
Voltage - Supply, Digital | 2.7V ~ 5.5V | |
Settling Time | 35ns (Typ) | |
Supplier Device Package | 28-SOIC | |
Architecture | Current Source | |
Number of D/A Converters | 1 | |
INL/DNL (LSB) | ±0.5, ±0.25 | |
Differential Output | Yes | |
DigiKey Programmable | Not Verified |
RESOURCE TYPE | LINK |
---|
ATTRIBUTE | DESCRIPTION | |
---|---|---|
ECCN | EAR99 | |
HTSUS | 8542.39.0001 | |
RoHS Status | RoHS non-compliant |
