HCPL-3760

HCPL-3760

Part Number	HCPL-3760
Manufacturer	Broadcom
Other Part Numbers	516-1133-5-ND HCPL3760 516-1133-5 2832-HCPL-3760
Description	OPTOISO 3.75KV DARLINGTON 8-DIP
Detailed Description	Optoisolator Darlington Output 3750Vrms 1 Channel 8-DIP
Manufacturer Standard Lead Time	20 weeks
Datasheet	Datasheet

Product Attributes

Category		Isolators Optoisolators Transistor, Photovoltaic Output Optoisolators
Manufacturer		Broadcom
Series
Packaging		Tube
Part Status		Active
Package / Case		8-DIP (0.300", 7.62mm)
Output Type		Darlington
Mounting Type		Through Hole
Operating Temperature		-40°C ~ 85°C
Input Type		AC, DC
Current - Output / Channel		30mA
Voltage - Isolation		3750Vrms
Supplier Device Package		8-DIP
Voltage - Output (Max)		20V
Turn On / Turn Off Time (Typ)		4.5µs, 8µs
Rise / Fall Time (Typ)		14µs, 0.4µs
Number of Channels		1
