GLSW4M202

Part Number
GLSW4M202
Manufacturer Sprague-Goodman
Other Part Numbers
SG9284CT-ND
Q2403753
SG9284CT
SG9284DKR
GLSW4M202-ND
SG9284
SG9284-ND
SG9284TR
Description INDUCT ARRAY 2 COIL SMD
Detailed Description Unshielded 2 Coil Inductor Array Inductance - Connected in Series Inductance - Connected in Parallel DC Resistance (DCR) - Parallel Nonstandard, 5 Lead
Datasheet Datasheet

Product Attributes

Category
Manufacturer Sprague-Goodman
Series
SURFCOIL® GLSW
Packaging
Cut Tape (CT)
Part Status Obsolete
Package / Case Nonstandard, 5 Lead
Size / Dimension 0.177" L x 0.177" W (4.50mm x 4.50mm)
Mounting Type Surface Mount
Shielding Unshielded
Operating Temperature -40°C ~ 125°C
Height 0.114" (2.90mm)
Number of Coils 2

Documents & Media

RESOURCE TYPE LINK
Datasheets GLSW4M202
Datasheets Multiple Devices 22-Jan-2020

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
ECCN EAR99
HTSUS 8504.31.4035
Moisture Sensitivity Level (MSL) 1 (Unlimited)
RoHS Status RoHS Compliant

Obsolete

This product is no longer manufactured.
