GDE25-1

GDE25-1

Part Number	GDE25-1
Manufacturer	Triad Magnetics
Other Part Numbers	237-1111-ND GDE251 237-1111 237-1111-NDR Q2629741
Description	TRANSF .350 OHM SINGL GATE DRIVE
Detailed Description	680µH Gate Drive Pulse Transformer 1:1 Through Hole
Manufacturer Standard Lead Time	3 weeks
Datasheet	Datasheet

Product Attributes

Category		Transformers Pulse Transformers
Manufacturer		Triad Magnetics
Series		GDE25
Packaging		Bulk
Part Status		Active
Inductance		680µH
Size / Dimension		1.100" L x 1.040" W (27.94mm x 26.42mm)
Mounting Type		Through Hole
Operating Temperature		-40°C ~ 80°C
Transformer Type		Gate Drive
Turns Ratio - Primary:Secondary		1:1
ET (Volt-Time)		540VµS
Height - Seated (Max)		1.200" (30.48mm)

Documents & Media

RESOURCE TYPE		LINK
Datasheets		GDE25-1
Datasheets		RoHS Statement

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8504.31.4035
Moisture Sensitivity Level (MSL)		Not Applicable
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant

In Stock: 782

Can ship immediately.
