G125-MS13405L2P _ Headers, Male Pins_Rectangular Connectors_Connectors, Interconnects

Part Number	G125-MS13405L2P
Manufacturer	Harwin
Other Part Numbers	G125-MS13405L2P-ND 3937-G125-MS13405L2P
Description	CONN HDR VERT 34POS
Detailed Description	Connector Header Surface Mount 34 position 0.049" (1.25mm)
Datasheet	Datasheet

Category		Connectors, Interconnects Rectangular Connectors Headers, Male Pins
Manufacturer		Harwin
Series		Gecko
Packaging		Strip
Part Status		Active
Features		Pick and Place
Connector Type		Header
Current Rating (Amps)		2A
Mounting Type		Surface Mount
Number of Positions		34
Number of Rows		2
Style		Board to Board or Cable
Operating Temperature		-65°C ~ 150°C
Contact Type		Male Pin
Fastening Type		Latch Lock
Number of Positions Loaded		All
Termination		Solder
Material Flammability Rating		UL94 V-0
Contact Material		Phosphor Bronze
Insulation Color		Green
Pitch - Mating		0.049" (1.25mm)
Contact Finish - Mating		Gold
Contact Finish - Post		Gold
Contact Shape		Circular
Insulation Height		0.193" (4.90mm)
Shrouding		Shrouded - 4 Wall
Insulation Material		Polyamide (PA4T), Nylon 4T
Row Spacing - Mating		0.049" (1.25mm)

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8536.69.4040
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
